Enclosed drive
D9h
D10h
E5h
E6h
Depth [mm (in)]
600 (23.6)
600 (23.6)
600 (23.6)
600 (23.6)
Weight [kg (lb)]
(2)
280 (617)
355 (783)
400 (882)
431 (950)
Input filter cabinet
D9h
D10h
E5h
E6h
Height [mm (in)]
(1)
2100 (82.7)
2100 (82.7)
2100 (82.7)
2100 (82.7)
Width [mm (in)]
400 (15.8)/600
(23.6)
400 (15.8)/600
(23.6)
600 (23.6)/800 (31.5)
600 (23.6)/800 (31.5)
Depth [mm (in)]
600 (23.6)
600 (23.6)
600 (23.6)
600 (23.6)
Weight [kg (lb)]
410 (904)
410 (904)/530
(1168)
530 (1168)
530 (1168)/955
(2105)
Input power options cabinet
D9h
D10h
E5h
E6h
Height [mm (in)]
(1)
–
2100 (82.7)
2100 (82.7)
2100 (82.7)
Width [mm (in)]
–
600 (23.6)
600 (23.6)
600 (23.6)
Depth [mm (in)]
–
600 (23.6)
600 (23.6)
600 (23.6)
Weight [kg (lb)]
–
380 (838)
380 (838)
380 (838)
Sine-wave filter cabinet
D9h
D10h
E5h
E6h
Height [mm (in)]
(1)
2100 (82.7)
2100 (82.7)
2100 (82.7)
2100 (82.7)
Width [mm (in)]
600 (23.6)
600 (23.6)
1200 (47.2)
1200 (47.2)
Depth [mm (in)]
600 (23.6)
600 (23.6)
600 (23.6)
600 (23.6)
Weight [kg (lb)]
384 (847)
384 (847)
768 (1693)
768 (1693)
dU/dt filter cabinet
D9h
D10h
E5h
E6h
Height [mm (in)]
(1)
–
–
2100 (82.7)
2100 (82.7)
Width [mm (in)]
(3)
–
–
400 (15.8)
400 (15.8)
Depth [mm (in)]
–
–
600 (23.6)
600 (23.6)
Weight [kg (lb)]
–
–
240 (529)
240 (529)
Top entry/exit cabinet
D9h
D10h
E5h
E6h
Height [mm (in)]
(1)
2100 (82.7)
2100 (82.7)
2100 (82.7)
2100 (82.7)
Width [mm (in)]
(3)
400 (15.8)
400 (15.8)
400 (15.8)
400 (15.8)
Depth [mm (in)]
600 (23.6)
600 (23.6)
600 (23.6)
600 (23.6)
Weight [kg (lb)]
164 (362)
164 (362)
164 (362)
164 (362)
1
Cabinet height includes standard 100 mm (3.9 in) pedestal. A 200 mm (7.9 in) or 400 mm (15.8 in) pedestal is optional.
2
Without options.
3
The E5h and E6h enclosures contain 2 sine-wave cabinets. The provided width is the total of both cabinets.
AQ262141314214en-000301 / 130R088032 | Danfoss A/S © 2021.11
Product Overview
VLT® HVAC Drive FC 102
Operating Guide
