Danfoss VACON OPTE3 - Setting the Termination Resistance

1
2
3
4
5
C
A
B
D
E
F
G
e30bi097.10
A
Data A +
B
Data B -
C
Shield
D
VP
E
Plus
F
Minus
G
Data Ground
Illustration 22: Fail-safe Biasing in OPTE2
1
2
3
4
5
C
A
B
D
E
F
G
e30bi098.10
A
Data A +
B
Data B -
C
Shield
D
VP
E
Plus
F
Minus
G
Data Ground
Illustration 23: Termination Resistance in OPTE2
5.4.3 Setting the Termination Resistance
Install termination resistance near both ends of the RS485 segment. The typical termination resistance for RS485 is 120 Ω.
D
C
D
E
A
B
e30bi072.10
