Table 2: RS485-based Serial Bus Option Boards
Option board
code
Option board
Compatible with AC drive
The correct
slots
(1)
Specific information
OPTE3/E5
PROFIBUS DP option
board
VACON
®
NXP
VACON
®
100 INDUSTRIAL, 100X, 100 FLOW
VACON
®
20, 20 X, 20 CP
D, E
PROFIBUS, PROFIsafe
OPTC3/C5
PROFIBUS DP option
board
VACON
®
NXP, NXS
D, E
PROFIBUS
OPTE2/E8
RS485 multiprotocol op-
tion board
VACON
®
NXP, NXS
VACON
®
100 INDUSTRIAL, 100X, 100
FLOW, 100 HVAC
VACON
®
20, 20X, 20CP
D, E
Modbus RTU, Metasys
N2
OPTC2/C8
Modbus/N2 option
board
VACON
®
NXP, NXS
D, E
Modbus RTU, Metasys
N2
OPTCJ
BACnet option board
VACON
®
NXP, NXS
D, E
BACnet MSTP
1
For option board installation in VACON® 20, a separate option board mounting kit is necessary.
1.4.2 CAN bus-based and Other Option Boards
The following table lists the CAN bus-based and other option boards compatible with VACON
®
AC drives.
Table 3: CAN bus-based and Other Option Boards
Option
board code
Option board
Compatible with AC drive
The correct
slots
(1)
Specific informa-
tion
OPTE6
CANopen option board
VACON
®
NXP, NXS
VACON
®
100 INDUSTRIAL, 100X, 100 FLOW
VACON
®
20, 20 X, 20CP
D, E
CANopen
OPTC6
CANopen option board
VACON
®
NXP, NXS
D, E
CANopen
OPTE7
DeviceNet option board
VACON
®
NXP
VACON
®
100 INDUSTRIAL, 100X, 100 FLOW
VACON
®
20, 20X, 20CP
D, E
DeviceNet
OPTC7
DeviceNet option board
VACON
®
NXP, NXS
D, E
DeviceNet
OPTC4
LonWorks option board
VACON
®
NXP, NXS
VACON
®
100 INDUSTRIAL, 100X, 100 FLOW
D, E
LonWorks
1
For option board installation in VACON
®
20, a separate option board mounting kit is necessary.
1.4.3 VACON® 100 Family Internal RS485 Fieldbus Protocols
VACON
®
100 INDUSTRIAL, 100 X, and 100 FLOW AC drives support internally the following RS485 fieldbus protocols:
Modbus RTU
BACnet MSTP
Metasys N2
For detailed installation instructions for the internal fieldbuses, see the Installation Manual of the AC drive in use.
