5 Specifications
5.1 General Specifications
Mains supply (L1, L2, L3)
Supply voltage 525-690 V -10/+5%
Mains voltage low/mains drop-out:
During low mains voltage or a mains drop-out, the frequency converters continues until the intermediate circuit voltage drops
below the minimum stop level, which corresponds typically to 15% below the drive's lowest rated supply voltage. Power-up and
full torque cannot be expected at mains voltage lower than 10% below the frequency converter’s lowest rated supply voltage.
Supply frequency 50/60 Hz ±5%
Max. imbalance temporary between mains phases 3.0% of rated supply voltage
True Power Factor (λ) ≥0.9 nominal at rated load
Displacement Power Factor (cos ϕ) near unity (> 0.98)
Switching on input supply L1, L2, L3 (power-ups) maximum 1 time/2 min.
Environment according to EN60664-1 over-voltage category III/pollution degree 2
The unit is suitable for use on a circuit capable of delivering not more than 100.000 RMS symmetrical Amperes, 500/600/690 V
maximum.
Torque characteristics
Overload torque (constant torque) maximum 150% (typical)/175% (1.2 MW and above) for 60 s
1)
1) Percentage relates to the nominal torque.
Digital inputs
Programmable digital inputs 4 (6)
Terminal number 18, 19, 27
1)
, 29, 32, 33,
Logic PNP or NPN
Voltage level 0-24 V DC
Voltage level, logic'0' PNP < 5 V DC
Voltage level, logic'1' PNP > 10 V DC
Voltage level, logic '0' NPN
2)
> 19 V DC
Voltage level, logic '1' NPN
2)
< 14 V DC
Maximum voltage on input 28 V DC
Pulse frequency range 0-110 kHz
(Duty cycle) Minimum pulse width 4.5 ms
Input resistance, R
i
approx.4 kΩ
Specifications Operating Instructions
