6.2 Parameters: 0-** Operation and Display
Parameters related to the basic functionality of the AFE.
Parameters related to the function of the display and
buttons.
6.2.1 0-0* Basic Settings
0-01 Language
Option: Function:
Defines the language to be used in the display.
[0] * English Part of Language packages 1 - 4
6.2.2 0-1* Set-up Operations
Define and control the individual parameter setups.
0-10 Active Set-up
Option: Function:
Select the set-up to control the frequency
converter functions.
[0] Factory
setup
Cannot be changed. It contains the Danfoss
data set, and can be used as a data source
when returning the other set-ups to a known
state.
[1] * Set-up 1
Set-up 1 [1] to Set-up 4 [4] are the four
separate parameter set-ups within which all
parameters can be programmed.
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
[9] Multi Set-
up
Remote selection of set-ups using digital
inputs and the serial communication port.
This set-up uses the settings from 0-12 This
Set-up Linked to. Stop the frequency converter
before making changes to open- and closed
loop functions
Required to use emergency mode.
0-11 Edit Set-up
Option: Function:
Editing can either follow the active setup
selection (parameter 0-10 Active Set-up), or be
fixed at a setup number. This parameter is
unique for LCP and buses.
[0] Factory setup
[1] * Set-up 1
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
[9] Active Set-up
0-12 This Set-up Linked to
Option: Function:
This parameter sets the AFE to automatically
synchronise the values of the 'not changeable
during operation' parameters between this set-
up and the set-up selected in this parameter.
Note: The values in this setup are overwritten.
[0] * Not linked
[1] Set-up 1
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
0-13 Readout: Linked Set-ups
Range: Function:
0* [0 -
255 ]
View a list of all the set-ups linked by means of
0-12 This Set-up Linked to. The parameter has one
index for each parameter set-up. The parameter
value displayed for each index represents which
set-ups are linked to that parameter set-up.
Index LCP value
0 {0}
1 {1,2}
2 {1,2}
3 {3}
4 {4}
Table 6.2 Example: Set-up 1 and Set-up 2 are
linked
0-14 Readout: Edit Set-ups / Channel
Range: Function:
0* [-2147483648 -
2147483647 ]
View the setting of 0-11 Edit Set-up for
each of the 4 different communication
channels. When the number is displayed
as a hex number, as it is in the LCP, each
number represents one channel.
Numbers 1-4 represent a set-up number;
‘F’ means factory setting; and ‘A’ means
active set-up. The channels are, from right
to left: LCP, FC-bus, USB, HPFB1-5.
Example: The number AAAAAA21h means
that the FC bus selected Set-up 2 in
0-11 Edit Set-up, the LCP selected Set-up 1
and all others used the active set-up.
How to Programme Operating Instructions
44 Danfoss A/S © Rev. 05/2014 All rights reserved. MG33X402
