Protection and Features
•
Temperature monitoring of the heatsink ensures that the frequency converter trips if the temperature reaches a
predefined level. An overload temperature cannot be reset until the temperature of the heatsink is below the
values stated in the tables on the following pages (Guideline - these temperatures may vary for different power
sizes, frame sizes, enclosure ratings etc.).
•
If a mains phase is missing, the frequency converter trips or issues a warning (depending on the load).
•
Monitoring of the DC voltage ensures that the frequency converter trips if the DC circuit voltage is too low or too
high.
•
The frequency converter constantly checks for critical levels of internal temperature, load current, and the DC
voltage. As a response to a critical level, the frequency converter can adjust the switching frequency and/ or
change the switching pattern to ensure the performance of the frequency converter.
5.2 Mains Supply
5.2.1 Mains Supply 3x525-690 V AC
AFE 302 P400 P800 P1200 P1600
Typical Input at 550 V [kW] 315 710 1000 1400
Typical Input at 630 V [kW] 400 800 1200 1600
Enclosure IP00 E1 IP54 F1 IP54 F2 IP54 F1*2
Continuous input current at 550 V [A] 429 889 1317 1652
Intermittent input current (60 s overload) at 550 V [A]
1)
644 1334 2305 2891
Typical DC voltage at 550 V [V] 850 850 850 850
Continuous output DC current at 550 V [A] 457 947 1403 1760
Continuous input current at 630 V [A] 410 850 1260 1580
Intermittent input current (60 s overload) at 630 V [A]
1)
615 1275 2205 2765
Typical DC voltage at 630 V [V] 975 975 975 975
Continuous output DC current at 630 V [A] 425 882 1307 1639
Max. Cable size, mains [mm
2
(AWG)]
4x240 (4x500
mcm)
8x150 (8x300
mcm)
12x150
(12x300mcm)
16x150
(16x300mcm)
Estimated power loss at 630 V [kW] 8 16 24 32
Weight IP00 for E and IP54 for F1 and F2 221 382 574 764
Weight Module [kg] NA 102 102 102
Effieciency
2)
0.98 0.98 0.98 0.98
Heatsink overtemp trip level [°C]
85 85 85 85
Power card ambient trip [°C]
68 68 68 68
Table 5.1 Mains Supply 3x525-690 V AC
1) The typical overload percentage is 150. The P1M2 to P1M6 overload percentage is 175.
2) The efficiency is estimated at the nominal load condition. It is expected to be within
±
15%. If the switching frequency is increased, the power
loss rises.
