Enclosure size F1 F2 F3 F4
Power rating
1)
Output at 400 V (kW) 500–710 800–1000 500–710 800–1000
Output at 460 V (hp) 650–1000 1200–1350 650–1000 1200–1350
Front-end conguration
6-pulse S S S S
12-pulse – – – –
Protection rating
IP IP21/54 IP21/54 IP21/54 IP21/54
UL type Type 1/12 Type 1/12 Type 1/12 Type 1/12
Hardware options
2)
Stainless steel back channel O O O O
Mains shielding – – – –
Space heater and thermostat O O O O
Cabinet light with power outlet O O O O
RFI lter (Class A1) – – – –
NAMUR terminals – – – –
Insulation resistance monitor (IRM) – – O O
Residual current monitor (RCM) – – O O
Brake chopper (IGBTs) O O O O
Safe Torque O O O O O
Regen terminals O O O O
Common motor terminals O O O O
Emergency stop with Pilz safety relay – – O O
Safe Torque O with Pilz safety relay O O O O
No LCP – – – –
Graphical LCP S S S S
Numerical LCP – – – –
Fuses O O O O
Load share terminals O O O O
Fuses + load share terminals O O O O
Disconnect – – O O
Circuit breakers – – O O
Contactors – – O O
Manual motor starters O O O O
30 A, fuse-protected terminals O O O O
24 V DC supply (SMPS, 5 A) O O O O
External temperature monitoring O O O O
Dimensions
Height, mm (in) 2204 (86.8) 2204 (86.8) 2204 (86.8) 2204 (86.8)
Width, mm (in) 1400 (55.1) 1800 (70.9) 2000 (78.7) 2400 (94.5)
Depth, mm (in) 606 (23.9) 606 (23.9) 606 (23.9) 606 (23.9)
Weight, kg (lb) 1017 (2242.1) 1260 (2777.9) 1318 (2905.7) 1561 (3441.5)
Table 4.4 F1–F4 Drives, 380–500 V
1) All power ratings are taken at normal overload. Output is measured at 400 V (kW) and 460 V (hp).
2) S = standard, O = optional, and a dash indicates that the option is unavailable.
