Enclosure size F8 F9 F10 F11 F12 F13
Power rating
1)
Output at 400 V (kW) 315–450 315–450 500–710 500–710 800–1000 800–1000
Output at 460 V (hp) 450–600 450–600 650–1000 650–1000 1200–1350 1200–1350
Front-end conguration
6-pulse – – – – – –
12-pulse S S S S S S
Protection rating
IP IP21/54 IP21/54 IP21/54 IP21/54 IP21/54 IP21/54
NEMA Type 1/12 Type 1/12 Type 1/12 Type 1/12 Type 1/12 Type 1/12
Hardware options
2)
Stainless steel back channel – – – – – –
Mains shielding – – – – – –
Space heater and thermostat – – O O O O
Cabinet light with power
outlet
– – O O O O
RFI lter (Class A1) – O – – O O
NAMUR terminals – – – – – –
Insulation resistance monitor
(IRM)
– O – – O O
Residual current monitor
(RCM)
– O – – O O
Brake chopper (IGBTs) O O O O O O
Safe Torque O O O O O O O
Regen terminals – – – – – –
Common motor terminals – – O O O O
Emergency stop with Pilz
safety relay
– – – – – –
Safe Torque O with Pilz
safety relay
O O O O O O
No LCP – – – – – –
Graphical LCP S S S S S S
Numerical LCP – – – – – –
Fuses O O O O O O
Load share terminals – – – – – –
Fuses + load share terminals – – – – – –
Disconnect – O O O O O
Circuit breakers – – – – – –
Contactors – – – – – –
Manual motor starters – – O O O O
30 A, fuse-protected terminals – – O O O O
24 V DC supply (SMPS, 5 A) O O O O O O
External temperature
monitoring
– – O O O O
Dimensions
Height, mm (in) 2204 (86.8) 2204 (86.8) 2204 (86.8) 2204 (86.8) 2204 (86.8) 2204 (86.8)
Width, mm (in) 800 (31.5) 1400 (55.2) 1600 (63.0) 2400 (94.5) 2000 (78.7) 2800 (110.2)
Depth, mm (in) 606 (23.9) 606 (23.9) 606 (23.9) 606 (23.9) 606 (23.9) 606 (23.9)
Weight, kg (lb) 447 (985.5) 669 (1474.9) 893 (1968.8) 1116 (2460.4) 1037 (2286.4) 1259 (2775.7)
Table 4.5 F8–F13 Drives, 380–480 V
1) All power ratings are taken at normal overload. Output is measured at 400 V (kW) and 460 V (hp).
2) S = standard, O = optional, and a dash indicates that the option is unavailable.
