Q3-30 Single Zone Int. Set Point Q3-31 Single Zone Ext. Set Point Q3-32 Multi Zone / Adv
20-82 PID Start Speed [RPM] Parameter 6-26 Terminal 54 Filter Time
Constant
20-13 Minimum Reference/Feedb.
20-83 PID Start Speed [Hz] Parameter 6-27 Terminal 54 Live Zero 20-14 Maximum Reference/Feedb.
Parameter 20-93 PID Proportional Gain Parameter 6-00 Live Zero Timeout Time Parameter 6-10 Terminal 53 Low Voltage
Parameter 20-94 PID Integral Time Parameter 6-01 Live Zero Timeout Function Parameter 6-11 Terminal 53 High Voltage
20-70 Closed Loop Type Parameter 20-81 PID Normal/ Inverse
Control
6-12 Terminal 53 Low Current
20-71 PID Performance 20-82 PID Start Speed [RPM] 6-13 Terminal 53 High Current
20-72 PID Output Change 20-83 PID Start Speed [Hz] Parameter 6-14 Terminal 53 Low Ref./Feedb.
Value
20-73 Minimum Feedback Level Parameter 20-93 PID Proportional Gain Parameter 6-15 Terminal 53 High Ref./Feedb.
Value
20-74 Maximum Feedback Level Parameter 20-94 PID Integral Time Parameter 6-16 Terminal 53 Filter Time
Constant
20-79 PID Autotuning 20-70 Closed Loop Type Parameter 6-17 Terminal 53 Live Zero
20-71 PID Performance Parameter 6-20 Terminal 54 Low Voltage
20-72 PID Output Change Parameter 6-21 Terminal 54 High Voltage
20-73 Minimum Feedback Level Parameter 6-22 Terminal 54 Low Current
20-74 Maximum Feedback Level Parameter 6-23 Terminal 54 High Current
20-79 PID Autotuning Parameter 6-24 Terminal 54 Low Ref./Feedb.
Value
Parameter 6-25 Terminal 54 High Ref./Feedb.
Value
Parameter 6-26 Terminal 54 Filter Time
Constant
Parameter 6-27 Terminal 54 Live Zero
Parameter 6-00 Live Zero Timeout Time
Parameter 6-01 Live Zero Timeout Function
Parameter 4-56 Warning Feedback Low
Parameter 4-57 Warning Feedback High
Parameter 20-20 Feedback Function
Parameter 20-21 Setpoint 1
Parameter 20-22 Setpoint 2
Parameter 20-81 PID Normal/ Inverse Control
20-82 PID Start Speed [RPM]
20-83 PID Start Speed [Hz]
Parameter 20-93 PID Proportional Gain
Parameter 20-94 PID Integral Time
20-70 Closed Loop Type
20-71 PID Performance
20-72 PID Output Change
20-73 Minimum Feedback Level
20-74 Maximum Feedback Level
20-79 PID Autotuning
Table 6.5 Q3-3 Closed Loop Settings
How to Programme
VLT HVAC Drive FC 102 Operating Instructions
90 MG11F402 - Rev. 2013-12-16
66
