[1682] Serial com. bus REF 1 Main reference value sent with control word via the serial communications network, e.g., from the
BMS, PLC or other master controller.
[1684] Comm. Option STW Extended serial communication option status word.
[1685] ADF Port CTW 1 Control word (CTW) received from the bus master.
[1686] AFD Port REF 1 Status word (STW) sent to the bus master.
[1690] Alarm Word One or more alarms in a Hex code (used for serial communications)
[1691] Alarm Word 2 One or more alarms in a Hex code (used for serial communications)
[1692] Warning Word One or more warnings in a Hex code (used for serial communications)
[1693] Warning Word 2 One or more warnings in a Hex code (used for serial communications)
[1694] Ext. Status Word One or more status conditions in a Hex code (used for serial communications)
[1695] Ext. Status Word 2 One or more status conditions in a Hex code (used for serial communications)
[1696] Maintenance Word The bits reflect the status for the preventive maintenance events programmed in parameter group
23-1*
[1830] Analog Input X42/1 Shows the value of the signal applied to terminal X42/1 on the Analog I/O card.
[1831] Analog Input X42/3 Shows the value of the signal applied to terminal X42/3 on the Analog I/O card.
[1832] Analog Input X42/5 Shows the value of the signal applied to terminal X42/5 on the Analog I/O card.
[1833] Analog Out X42/7 [V] Shows the value of the signal applied to terminal X42/7 on the Analog I/O card.
[1834] Analog Out X42/9 [V] Shows the value of the signal applied to terminal X42/9 on the Analog I/O card.
[1835] Analog Out X42/11 [V] Shows the value of the signal applied to terminal X42/11 on the Analog I/O card.
[2117] Ext. 1 Reference [Unit] The value of the reference for extended Closed-loop Controller 1
[2118] Ext. 1 Feedback [Unit] The value of the feedback signal for extended Closed-loop Controller 1
[2119] Ext. 1 Output [%] The value of the output from extended Closed-loop Controller 1
[2137] Ext. 2 Reference [Unit] The value of the reference for extended Closed-loop Controller 2
[2138] Ext. 2 Feedback [Unit] The value of the feedback signal for extended Closed-loop Controller 2
[2139] Ext. 2 Output [%] The value of the output from extended Closed-loop Controller 2
[2157] Ext. 3 Reference [Unit] The value of the reference for extended Closed-loop Controller 3
[2158] Ext. 3 Feedback [Unit] The value of the feedback signal for extended Closed-loop Controller 3
[2159] Ext. Output [%] The value of the output from extended Closed-loop Controller 3
[2230] No-Flow Power The calculated No-Flow Power for the actual operating speed
[2580] Cascade Status Status for the operation of the cascade controller
[2581] Pump Status Status for the operation of each individual pump controlled by the cascade controller
[2791] Cascade Reference Reference output for use with follower drives.
[2792] % Of Total Capacity Readout parameter to show the system operating point as a % capacity of total system capacity.
[2793] Cascade Option Status Readout parameter to show the status of the cascade system.
0-21 Display Line 1.2 Small
Option: Function:
Select a variable for display in line 1, middle position.
[1662] * Analog input 53 The options are the same as those listed for par. 0-20
Display Line 1.1 Small
.
0-22 Display Line 1.3 Small
Option: Function:
Select a variable for display in line 1, right position.
[1614] * Motor Current The options are the same as those listed for par. 0-20
Display Line 1.1 Small
.
6 How to Program the Low Harmonic Drive
VLT AQUA Low Harmonic Drive Instruction
Manual
6-12
