4.7 Connection Examples for Control of Motor with External Signal Pro-
vider
NOTE!
The following examples refer only to the drive control card (right LCP),
not
the filter.
4.7.1 Start/Stop
Terminal 18 = par. 5-10
Terminal 18 Digital Input
[8]
Start
Terminal 27 = par. 5-12
Terminal 27 Digital Input
[0]
No operation
(De-
fault
coast inverse
)
Terminal 37 = Safe stop
VLT AQUA Low Harmonic Drive Instruction
Manual
4 How to Install
MG.20.T1.22 - VLT
®
is a registered Danfoss trademark
4-55
4
To Next Page
