Frame size F17
Enclosure protection
IP 21/54*
NEMA Type 1
Normal overload rated power - 110% over-
load torque
670–952 hp [500–710 kW] at 400 V
(380–480 V)
Shipping Dimensions - filter
section/ drive section
Height 2324/ 2324
Width 2578/ 1569
Depth 1130/ 1130
Drive Dimensions Height 86.62 in [2200 mm]
Width 145.7 in [3700 mm]
Depth 23.62 in [600 mm]
Max Weight 4410 lbs [2000 kg]
* Hybrid IP54 electronics, IP21 magnetics
VLT AQUA Low Harmonic Drive Instruction
Manual
4 How to Install
MG.20.T1.22 - VLT
®
