Size/Type Bussmann PN* Rating Siba
P500 170M8611 1100 A, 1000 V 20 781 32.1000
P560 170M8611 1100 A, 1000 V 20 781 32.1000
P630 170M6467 1400 A, 700 V 20 681 32.1400
P710 170M6467 1400 A, 700 V 20 681 32.1400
Table 4.6: Frame size F, Inverter module DC Link Fuses, 380–480 V
*170M fuses from Bussmann shown use the -/80 visual indicator; -TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and amperage
may be substituted for external use
**Any minimum 500 V UL listed fuse with associated current rating may be used to meet UL requirements.
Supplementary fuses
Frame size Bussmann PN* Rating
D, E and F KTK-4 4 A, 600 V
Table 4.7: SMPS Fuse
Size/Type Bussmann PN* LittelFuse Rating
P160-P315, 380–480 V KTK-4 4 A, 600 V
P355-P710, 380–480 V KLK-15 15A, 600 V
Table 4.8: Fan Fuses
Size/Type Bussmann PN* Rating Alternative Fuses
P500-P710, 380–480 V 2.5–4.0 A LPJ-6 SP or SPI 6 A, 600 V Any listed Class J Dual Ele-
ment, Time Delay, 6 A
P500-P710, 380–480 V 4.0–6.3 A LPJ-10 SP or SPI 10 A, 600 V Any listed Class J Dual Ele-
ment, Time Delay, 10 A
P500-P710, 380–480 V 6.3–10 A LPJ-15 SP or SPI 15 A, 600 V Any listed Class J Dual Ele-
ment, Time Delay, 15 A
P500-P710, 380–480 V 10–16 A LPJ-25 SP or SPI 25 A, 600 V Any listed Class J Dual Ele-
ment, Time Delay, 25 A
Table 4.9: Manual Motor Controller Fuses
Frame size Bussmann PN* Rating Alternative Fuses
F LPJ-30 SP or SPI 30 A, 600 V Any listed Class J Dual Element, Time
Delay, 30 A
Table 4.10: 30 A Fuse Protected Terminal Fuse
Frame size Bussmann PN* Rating Alternative Fuses
D LP-CC-8/10 0.8 A, 600 V Any listed Class CC, 0.8 A
E LP-CC-1 1/2 1.5 A, 600 V Any listed Class CC, 1.5 A
F LPJ-6 SP or SPI 6 A, 600 V Any listed Class J Dual Element, Time
Delay, 6 A
Table 4.11: Control Transformer Fuse
Frame size Bussmann PN* Rating
F GMC-800MA 800 mA, 250 V
Table 4.12: NAMUR Fuse
4 How to Install
VLT AQUA Low Harmonic Drive Instruction
Manual
4-50
MG.20.T1.22 - VLT
®
is a registered Danfoss trademark
