[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[75] Start command given
[76] Digital input x30 2
[77] Digital input x30 3
[78] Digital input x30 4
[79] Digital input x46 1
[80] Digital input x46 3
[81] Digital input x46 5
[82] Digital input x46 7
[83] Digital input x46 9
[84] Digital input x46 11
[85] Digital input x46 13
13-52 SL Controller Action
Array [20]
Option: Function:
[0] * DISABLED Select the action corresponding to the SLC event. Actions are executed when the corresponding
event (defined in par. 13-51
SL Controller Event ) is evaluated as true. The following actions are
available for selection:
*DISABLED [0]
[1] No action
No action [1]
[2] Select set-up 1
Select set-up 1 [2] - changes the active set-up (par. 0-10) to ‘1’.
If the set-up is changed, it will merge with other set-up commands coming from either the digital
inputs or via a fieldbus.
[3] Select set-up 2
Select set-up 2 [3] - changes the active set-up (par. 0-10) to ‘2’.
If the set-up is changed, it will merge with other set-up commands coming from either the digital
inputs or via a fieldbus.
[4] Select set-up 3
Select set-up 3 [4] - changes the active set-up (par. 0-10) to ‘3’.
If the set-up is changed, it will merge with other set-up commands coming from either the digital
inputs or via a fieldbus.
[5] Select set-up 4
Select set-up 4 [5] - changes the active set-up (par. 0-10) to ‘4’.
FC 300 Programming Guide 3 Parameter descriptions
MG.33.M8.02 - VLT
®
is a registered Danfoss trademark 191
3
