Danfoss VLT AutomationDrive FC 300 Programming Guide

2.1.5 Display Mode - Selection of Read-Outs
It is possible to toggle between three status read-out screens by pressing
the [Status] key.
Operating variables with different formatting are shown in each status
screen - see below.
The table shows the measurements you can link to each of the operating
variables. When Options are mounted, additional measurements are
available. Define the links via par. 0-20
Display Line 1.1 Small ,
par. 0-21
Display Line 1.2 Small , par. 0-22 Display Line 1.3 Small ,
par. 0-23
Display Line 2 Large , and par. 0-24 Display Line 3 Large .
Each readout parameter selected in par. 0-20
Display Line 1.1 Small to
par. 0-24
Display Line 3 Large has its own scale and digits after a possible
decimal point. By larger numeric value of a parameter fewer digits are
displayed after the decimal point.
Ex.: Current readout
5.25 A; 15.2 A 105 A.
Operating variable: Unit:
Par. 16-00 Control Word hex
Par. 16-01
Reference [Unit] [unit]
Par. 16-02 Reference [%] %
Par. 16-03
Status Word hex
Par. 16-05 Main Actual Value [%] %
Par. 16-10
Power [kW] [kW]
Par. 16-11 Power [hp] [HP]
Par. 16-12
Motor Voltage [V]
Par. 16-13 Frequency [Hz]
Par. 16-14
Motor Current [A]
Par. 16-16 Torque [Nm] Nm
Par. 16-17
Speed [RPM] [RPM]
Par. 16-18 Motor Thermal %
Par. 16-20
Motor Angle
Par. 16-30 DC Link Voltage V
Par. 16-32
Brake Energy /s kW
Par. 16-33 Brake Energy /2 min kW
Par. 16-34
Heatsink Temp. C
Par. 16-35 Inverter Thermal %
Par. 16-36
Inv. Nom. Current A
Par. 16-37 Inv. Max. Current A
Par. 16-38
SL Controller State
par. 16-39 Control Card Temp. C
Par. 16-40
Logging Buffer Full
Par. 16-50 External Reference
Par. 16-51
Pulse Reference
Par. 16-52 Feedback [Unit] [Unit]
Par. 16-53
Digi Pot Reference
Par. 16-60 Digital Input bin
Par. 16-61
Terminal 53 Switch Setting V
Par. 16-62 Analog Input 53
Par. 16-63
Terminal 54 Switch Setting V
Par. 16-64 Analog Input 54
par. 16-65
Analog Output 42 [mA] [mA]
Par. 16-66 Digital Output [bin] [bin]
Par. 16-67
Pulse Input #29 [Hz] [Hz]
Par. 16-68 Freq. Input #33 [Hz] [Hz]
Par. 16-69
Pulse Output #27 [Hz] [Hz]
Par. 16-70 Pulse Output #29 [Hz] [Hz]
Par. 16-71
Relay Output [bin]
Par. 16-72 Counter A
Par. 16-73
Counter B
Par. 16-80 Fieldbus CTW 1 hex
Par. 16-82
Fieldbus REF 1 hex
Par. 16-84 Comm. Option STW hex
Par. 16-85
FC Port CTW 1 hex
Par. 16-86 FC Port REF 1 hex
Par. 16-90
Alarm Word
Par. 16-92 Warning Word
Par. 16-94
Ext. Status Word
FC 300 Programming Guide 2 How to Programme
MG.33.M8.02 - VLT
®
is a registered Danfoss trademark 19
