16-38 SL Controller State
Range: Function:
0* [0 - 100 ] View the state of the event under execution by the SL controller.
16-39 Control Card Temp.
Range: Function:
0 C* [0 - 100 C] View the temperature on the control card, stated in °C.
16-40 Logging Buffer Full
Option: Function:
View whether the logging buffer is full (see parameter group 15-1*). The logging buffer will never
be full when par. 15-13
Logging Mode
is set to
Log always
[0].
[0] * No
[1] Yes
16-49 Current Fault Source
Range: Function:
0* [0 - 8 ] Value indicates source of current faults including short circuit, over current, and phase imbalance
(from left):
1-4 Inverter
5-8 Rectifier
0 No fault recorded
3.17.5 16-5* Ref. & Feedb.
Parameters for reporting the reference and feedback input.
16-50 External Reference
Range: Function:
0.0* [-200.0 - 200.0 ] View the total reference, the sum of digital, analog, preset, bus and freeze references, plus catch-
up and slow-down.
16-51 Pulse Reference
Range: Function:
0.0* [-200.0 - 200.0 ] View the reference value from programmed digital input(s). The read-out can also reflect the im-
pulses from an incremental encoder.
16-52 Feedback [Unit]
Range: Function:
0.000 Ref-
erenceFeed-
backUnit*
[-999999.999 - 999999.999 Refer-
enceFeedbackUnit]
View the feedback unit resulting from the selection of unit and scaling in par. 3-00
Reference
Range
, par. 3-01
Reference/Feedback Unit
, par. 3-02
Minimum Reference
and par. 3-03
Maximum
Reference
.
16-53 Digi Pot Reference
Range: Function:
0.00* [-200.00 - 200.00 ] View the contribution of the Digital Potentiometer to the actual reference.
FC 300 Programming Guide 3 Parameter descriptions
MG.33.M8.02 - VLT
®
is a registered Danfoss trademark
215
