[71] bar
[72] Pa
[73] kPa
[74] m WG
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[150] lb ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[180] HP
3-02 Minimum Reference
Range: Function:
Application
dependent*
[Application dependant] Enter the Minimum Reference. The Minimum Reference is the lowest value obtainable by summing
all references.
Minimum Reference is active only when par. 3-00
Reference Range
is set to
Min.- Max.
[0].
The Minimum Reference unit matches:
• The choice of configuration in par. 1-00
Configuration Mode
Configuration Mode
: for
Speed
closed loop
[1], RPM; for
Torque
[2], Nm.
• The unit selected in par. 3-01
Reference/Feedback Unit
.
3-03 Maximum Reference
Range: Function:
Application
dependent*
[Application dependant] Enter the Maximum Reference. The Maximum Reference is the highest value obtainable by summing
all references.
The Maximum Reference unit matches:
• The choice of configuration in par. 1-00
Configuration Mode
: for
Speed closed loop
[1],
RPM; for
Torque
[2], Nm.
• The unit selected in par. 3-00
Reference Range
.
3 Parameter descriptions FC 300 Programming Guide
72
MG.33.M8.02 - VLT
®
is a registered Danfoss trademark
3
