Danfoss VLT AutomationDrive FC 300 - Page 223

Danfoss VLT AutomationDrive FC 300
277 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Loading...
17-25 Clock Rate
Range: Function:
Application
dependent*
[Application dependant] Set the SSI clock rate. With long encoder cables the clock rate must be reduced.
17-26 SSI Data Format
Option: Function:
[0] * Gray code
[1] Binary code Set the data format of the SSI data. Choose between Gray or Binary format.
17-34 HIPERFACE Baudrate
Select the baud rate of the attached encoder.
This parameter cannot be adjusted while the motor is running. The parameter is only accessible when par. 17-20
Protocol Selection
is set to HIPERFACE
[1].
Option: Function:
[0] 600
[1] 1200
[2] 2400
[3] 4800
[4] * 9600
[5] 19200
[6] 38400
3.18.4 17-5* Resolver Interface
Parameter group 17-5* is used for setting parameters for the MCB 103 Resolver Option.
Usually the resolver feedback is used as motor feedback from Permanent Magnet motors with par. 1-01
Motor Control Principle
set to Flux with motor
feedback.
Resolver parameters cannot be adjusted while the motor is running.
17-50 Poles
Range: Function:
2* [2 - 2 ] Set the number of poles on the resolver.
The value is stated in the data sheet for resolvers.
17-51 Input Voltage
Range: Function:
7.0 V* [2.0 - 8.0 V] Set the input voltage to the resolver. The voltage is stated as RMS value.
The value is stated in the data sheet for resolvers
17-52 Input Frequency
Range: Function:
10.0 kHz* [2.0 - 15.0 kHz] Set the input frequency to the resolver.
The value is stated in the data sheet for resolvers.
17-53 Transformation Ratio
Range: Function:
0.5* [0.1 - 1.1 ] Set the transformation ratio for the resolver.
The transformation ration is:
T
ratio
=
V
Out
V
In
3 Parameter descriptions FC 300 Programming Guide
222
MG.33.M8.02 - VLT
®
is a registered Danfoss trademark
3
