Danfoss VLT AutomationDrive FC 300 Programming Guide

Functions in group 1 have higher priority than functions in group 2.
Group 1 Reset, Coasting stop, Reset and Coasting
stop, Quick-stop, DC braking, Stop and the
"Off" key.
Group 2 Start, Pulse start, Reversing, Start reversing,
Jog and Freeze output
Motor:
Motor Running
Torque generated on output shaft and speed from zero rpm to max. speed on motor.
f
JOG
Motor frequency when the jog function is activated (via digital terminals).
f
M
Motor frequency.
f
MAX
Maximum motor frequency.
f
MIN
Minimum motor frequency.
f
M,N
Rated motor frequency (nameplate data).
I
M
Motor current (actual).
I
M,N
Rated motor current (nameplate data).
n
M,N
Rated motor speed (nameplate data).
n
s
Synchronous motor speed
n
s
=
2× par . 1 − 23 × 60 s
par
. 1 − 39
P
M,N
Rated motor power (nameplate data in kW or HP).
T
M,N
Rated torque (motor).
U
M
Instantaneous motor voltage.
U
M,N
Rated motor voltage (nameplate data).
FC 300 Programming Guide 1 Introduction
MG.33.M8.02 - VLT
®
is a registered Danfoss trademark 5
1
