Danfoss VLT AutomationDrive FC 301 Programming Guide

•
•
•
•
Parameter 3-02 Minimum Reference
Table 185: Parameter 3-02 Minimum Reference
3-02 Minimum Reference
Default value: Size related
Parameter type: Range, -999999.999 - 999999.999 Reference- Feed-
backUnit
Setup: All setups
Conversion index: -3
Data type: Int32
Change during operation: True
Enter the minimum reference. The minimum reference is the lowest value obtainable by summing all references. Minimum refer-
ence is active only when parameter 3-00 Reference Range is set to [0] Min.- Max. The minimum reference unit matches:
The configuration of parameter 1-00 Configuration Mode: For [1] Speed closed loop, RPM; for [2] Torque, Nm.
The unit selected in parameter 3-01 Reference/ Feedback Unit.
If option [10] Synchronization is selected in parameter 1-00 Configuration Mode, this parameter defines the maximum speed devia-
tion when performing the position offset defined in parameter 3-26 Master Offset. Also see parameter 3-28 Master Offset Speed Ref.
Parameter 3-03 Maximum Reference
Table 186: Parameter 3-03 Maximum Reference
3-03 Maximum Reference
Default value: Size related
Parameter type: 0.000 - 999999.999 Reference- FeedbackUnit
Setup: All setups
Conversion index: -3
Data type: Int32
Change during operation: True
Enter the maximum reference. The maximum reference is the highest value obtainable by summing all references. The maximum
reference unit matches:
The configuration selected in parameter 1-00 Configuration Mode: For [1] Speed closed loop, RPM; for [2] Torque, Nm.
The unit selected in parameter 3-00 Reference Range.
If [9] Positioning is selected in parameter 1-00 Configuration Mode, this parameter defines the default speed for positioning.
Parameter 3-04 Reference Function
Table 187: Parameter 3-04 Reference Function
3-04 Reference Function
Default value: [0] Sum
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
Option
Name
Description
[0]*
Sum
Sums both external and preset reference sources.
[1]
External/Preset
Use either the preset or the external reference source. Shift between external and preset via a com-
mand or a digital input.
Parameter 3-05 On Reference Window
Table 188: Parameter 3-05 On Reference Window
3-05 On Reference Window
Default value: Size related
Parameter type: Range, 0 - 999999.999 Reference- FeedbackUnit
Setup: All setups
Conversion index: -3
Data type: Int32
Change during operation: True
N O T I C E
This parameter is only available with software version 48.XX
AU275636650261en-000101 / 130R0334126 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
