Select the output mode of analog terminal X49/11.
Option
Name
Description
[0]*
Voltage 0–10V
[1]
Voltage 2–10V
[2]
Current 0–20mA
[3]
Current 4–20mA
[4]
Digital
N O T I C E
This option is only available in FC 302.
5.29.2 36-1* Analog Input X49/1
N O T I C E
This parameter group is only available in FC 301.
Parameter 36-10 Terminal X49/1 Low Voltage
Table 1309: Parameter 36-10 Terminal X49/1 Low Voltage
36-10 Terminal X49/1 Low Voltage
Default value: 0.07 V
Parameter type: Range, 0 - 10 V
Setup: All setups
Conversion index: 0
Data type: Int16
Change during operation: True
Parameter 36-11 Terminal X49/1 Low Current
Table 1310: Parameter 36-11 Terminal X49/1 Low Current
36-11 Terminal X49/1 Low Current
Default value: 4 mA
Parameter type: Range, 0 - 20 mA
Setup: All setups
Conversion index: -3
Data type: Int16
Change during operation: True
Parameter 36-12 Terminal X49/1 High Voltage
Table 1311: Parameter 36-12 Terminal X49/1 High Voltage
36-12 Terminal X49/1 High Voltage
Default value: 10 V
Parameter type: Range, 0 - 10 V
Setup: All setups
Conversion index: 0
Data type: Int16
Change during operation: True
Parameter 36-13 Terminal X49/1 High Current
Table 1312: Parameter 36-13 Terminal X49/1 High Current
36-13 Terminal X49/1 High Current
Default value: 20 mA
Parameter type: Range, 0 - 20 mA
Setup: All setups
Conversion index: -3
Data type: Int16
Change during operation: True
AU275636650261en-000101 / 130R0334 | 639Danfoss A/S © 2022.12
