VLT
®
AutomationDrive FC 301/FC 302 standard terminals are 18, 19, 27, 29, 32, and 33. VLT® General Purpose I/O MCB 101 terminals
are X30/2, X30/3, and X30/4. In FC 302, terminal 29 also functions as an output.
Functions dedicated to only 1 digital input are stated in the associated parameter.
All digital inputs can be programmed to these functions:
Table 328: Digital Inputs, Function Descriptions - 1
No reaction to signals transmitted to the terminal.
Resets the drive after a trip/alarm. Not all alarms can be reset.
(Default digital input 27): Coast stop, inverted input (NC). The drive leaves the motor in free mode. Logic
0⇒coast stop.
Reset and coast stop inverted input (NC). Leaves the motor in free mode and resets the drive. Logic
0⇒coast stop and reset.
Inverted input (NC). Generates a stop in accordance with quick stop ramp time set in parameter 3-81
Quick Stop Ramp Time. When the motor stops, the shaft is in free mode. Logic 0⇒quick stop.
AU275636650261en-000101 / 130R0334 | 179Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
