This option selects between absolute and relative positioning. The option is valid for the next position-
ing command.
N O T I C E
This option is only available with software version 48.XX.
Positioning mode: The drive activates the selected positioning type and target, and starts the motion
towards the new target. The motion starts either immediately or when active positioning is completed,
depending on the settings of parameter 17-90 Absolute Position Mode and parameter 17-91 Relative Posi-
tion Mode.
Synchronization mode: High signal locks the actual follower position to the actual master position. The
follower starts and catches up with the master. Low signal stops the synchronization and the follower
makes a controlled stop.
N O T I C E
This option is only available with software version 48.XX.
Select positioning in synchronization mode.
N O T I C E
This option is only available with software version 48.XX.
Normally-open contact for defining the home position. The function is defined in parameter 17-80
Homing Function.
N O T I C E
This option is only available with software version 48.XX.
Normally-closed contact for defining the home position. The function is defined in parameter 17-80
Homing Function.
N O T I C E
This option is only available with software version 48.XX.
Normally-open contact. Serves as a reference for touch probe positioning.
N O T I C E
This option is only available with software version 48.XX.
Normally-closed contact. Serves as a reference for touch probe positioning.
N O T I C E
This option is only available with software version 48.XX.
AU275636650261en-000101 / 130R0334186 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
