Option
Name
Description
[108]
PPO 8
[200]
Custom telegram 1
Enables use of freely configurable telegrams or standard telegrams for the FC port.
[202]
Custom telegram 3
Parameter 8-41 Parameters for Signals
Table 519: Parameter 8-41 Parameters for Signals
8-41 Parameters for Signals
Default value: [0] None
Parameter type: Option, Array [1000]
Setup: All setups
Conversion index: –
Data type: Uint16
Change during operation: False
Option
Name
Description
[0]*
None
[15]
Readout: actual setup
[302]
Minimum reference
[303]
Maximum reference
[312]
Catch up/slow down value
[321]
Touch target
[322]
Master scale numerator
[323]
Master scale denominator
[326]
Master offset
[328]
Master offset speed ref
[341]
Ramp 1 ramp up time
[342]
Ramp 1 ramp down time
[351]
Ramp 2 ramp up time
[352]
Ramp 2 ramp down time
[380]
Jog/homing ramp time
[381]
Quick stop ramp time
[411]
Motor speed low limit [RPM]
[412]
Motor speed low limit [Hz]
[413]
Motor speed high limit [RPM]
[414]
Motor speed high limit [Hz]
[416]
Torque limit motor mode
[417]
Torque limit generator mode
[482]
Power limit motor mode
AU275636650261en-000101 / 130R0334290 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
