Danfoss VLT AutomationDrive FC 301 Programming Guide

Option
Name
Description
[106]
Relay 5
X47/VLT® Extended Relay Card MCB 113.
[107]
Relay 6
X47/VLT® Extended Relay Card MCB 113.
[108]
Relay 7
X34/VLT® Relay Card MCB 105.
[109]
Relay 8
X34/VLT® Relay Card MCB 105.
[110]
Relay 9
X34/VLT® Relay Card MCB 105.
[212]
Emergency mode
[222]
Homing OK
N O T I C E
This option is only available with software version 48.2X and newer.
Homing is completed with the selected homing function (parameter 17-80 Homing Function).
[223]
On target
N O T I C E
This option is only available with software version 48.2X and newer.
Positioning is completed and the on-target signal is sent when the actual position is within
parameter 3-05 On Reference Window for the duration of parameter 3-09 On Target Time and
the actual speed does not exceed parameter 3-05 On Reference Window.
[224]
Position error
N O T I C E
This option is only available with software version 48.2X and newer.
The position error exceeds the value in parameter 4-71 Maximum Position Error for the time
set in parameter 4-72 Position Error Timeout.
[225]
Position limit
N O T I C E
This option is only available with software version 48.2X and newer.
The position is outside the limits set in parameter 3-06 Minimum Position and parameter 3-07
Maximum Position.
[226]
Touch on target
N O T I C E
This option is only available with software version 48.2X and newer.
Target position is reached in touch probe position mode.
[227]
Touch activated
N O T I C E
This option is only available with software version 48.2X and newer.
Touch probe positioning active. The drive monitors the touch probe sensor input.
[228]
Comparator 6
AU275636650261en-000101 / 130R0334 | 397Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
