Danfoss VLT AutomationDrive FC 301 Programming Guide

Option
Name
Description
[46]
Right key
[▹] is pressed. Only available on the graphical LCP.
[47]
Up key
[▵] is pressed. Only available on the graphical LCP.
[48]
Down key
[▿] is pressed. Only available on the graphical LCP.
[50]
Comparator 4
Use the result of comparator 4.
[51]
Comparator 5
Use the result of comparator 5.
[60]
Logic rule 4
Use the result of logic rule 4.
[61]
Logic rule 5
Use the result of logic rule 5.
[70]
SL time-out 3
[71]
SL time-out 4
[72]
SL time-out 5
[73]
SL time-out 6
[74]
SL time-out 7
[75]
Start command given
[76]
Digital input X30/2
[77]
Digital input X30/3
[78]
Digital input X30/4
[79]
Digital input X46/1
[80]
Digital input X46/3
[81]
Digital input X46/5
[82]
Digital input X46/7
[83]
Digital input X46/9
[84]
Digital input X46/11
[85]
Digital input X46/13
[90]
ATEX ETR cur. warning
Available if parameter 1-90 Motor Thermal Protection is set to [20] ATEX ETR or [21] Advanced
ETR. If alarm 164, ATEX ETR cur.lim.alarm is active, the output is 1.
[91]
ATEX ETR cur. alarm
Available if parameter 1-90 Motor Thermal Protection is set to [20] ATEX ETR or [21] Advanced
ETR. If alarm 166, ATEX ETR freq.lim.alarm is active, the output is 1.
[92]
ATEX ETR freq. warning
Available if parameter 1-90 Motor Thermal Protection is set to [20] ATEX ETR or [21] Advanced
ETR. If alarm 163, ATEX ETR cur.lim.warning is active, the output is 1.
[93]
ATEX ETR freq. alarm
Available if parameter 1-90 Motor Thermal Protection is set to [20] ATEX ETR or [21] Advanced
ETR. If warning 165, ATEX ETR freq.lim.warning is active, the output is 1.
[94]
RS Flipflop 0
See parameter group 13-1* Comparators.
[95]
RS Flipflop 1
See parameter group 13-1* Comparators.
[96]
RS Flipflop 2
See parameter group 13-1* Comparators.
AU275636650261en-000101 / 130R0334 | 411Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
