Danfoss VLT AutomationDrive FC 360 User Manual

Frequency converter typical
shaft output [kW (hp)]
H11K
11
(15)
H15K
15
(20)
H18K
18.5
(25)
H22K
22
(30)
H30K
30
(40)
H37K
37
(50)
H45K
45
(60)
H55K
55
(75)
H75K
75
(100)
Enclosure protection rating
IP20
J4 J4 J5 J5 J6 J6 J6 J7 J7
Output current
Continuous (3x380–440 V) [A] 23 31 37 42.5 61 73 90 106 147
Continuous (3x441–480 V) [A] 21 27 34 40 52 65 77 96 124
Intermittent (60 s overload) [A] 34.5 46.5 55.5 63.8 91.5 109.5 135 159 220.5
Continuous kVA (400 V AC)
[kVA]
15.94 21.48 25.64 29.45 42.3 50.6 62.4 73.4 101.8
Continuous kVA (480 V AC)
[kVA]
17.5 22.4 28.3 33.3 43.2 54.0 64.0 79.8 103.1
Maximum input current
Continuous (3x380–440 V) [A] 22.1 29.9 35.2 41.5 57 70.3 84.2 102.9 140.3
Continuous (3x441–480 V) [A] 18.4 24.7 29.3 34.6 49.3 60.8 72.7 88.8 121.1
Intermittent (60 s overload) [A] 33.2 44.9 52.8 62.3 85.5 105.5 126.3 154.4 210.5
Additional specications
Maximum cable size (mains,
motor, brake) [mm
2
(AWG)]
16 (6) 50 (1/0) 85 (3/0)
Estimated power loss at rated
maximum load [W]
2)
289.53 393.36 402.83 467.52 630 848 1175 1250 1507
Weight [kg (lb)], enclosure
protection rating IP20
9.4 (20.7) 9.5 (20.9)
12.3
(27.1)
12.5
(27.6)
22.4
(49.4)
22.5
(49.6)
22.6 (49.8) 37.3 (82.2) 38.7 (85.3)
Eciency [%]
3)
97.8 97.8 98.1 97.9 98.1 98.0 97.7 98.0 98.2
Table 8.2 Mains Supply 3x380–480 V AC - Heavy Duty
