9 Appendix
9.1 Symbols, Abbreviations, and Conventions
°C
Degrees Celsius
°F
Degrees Fahrenheit
AC Alternating current
AEO Automatic energy optimization
AWG American wire gauge
AMA Automatic motor adaptation
AM motor Asynchronous motor
DC Direct current
EMC Electromagnetic compatibility
ETR Electronic thermal relay
f
M,N
Nominal motor frequency
FC Frequency converter
GLCP Graphical local control panel
I
INV
Rated inverter output current
I
LIM
Current limit
I
M,N
Nominal motor current
I
VLT,MAX
Maximum output current
I
VLT,N
Rated output current supplied by the frequency converter
IP Ingress protection
LCP Local control panel
MCT Motion control tool
NLCP Numerical local control panel
n
s
Synchronous motor speed
P
M,N
Nominal motor power
PELV Protective extra low voltage
PCB Printed circuit board
PM motor Permanent magnet motor
PWM Pulse width modulation
RPM Revolutions per minute
T
LIM
Torque limit
U
M,N
Nominal motor voltage
Table 9.1 Symbols and Abbreviations
Conventions
•
For illustrations, all dimensions are in [mm (in)].
•
An asterisk (*) indicates the default setting of a parameter.
•
Numbered lists indicate procedures.
•
Bullet lists indicate other information.
•
Italicized text indicates:
- Cross-reference.
- Link.
- Parameter name.
9.2
Parameter Menu Structure
Appendix
VLT
®
AutomationDrive FC 360
