Danfoss VLT AutomationDrive FC 360 User Manual

0-** Operation / Display 0-0* Basic Settings 0-01 Language *[0] English [10] Chinese [28] Bras.port 0-03 Regional Settings *[0] International [1] North America 0-04 Operating State at Power-up [0] Resume *[1] Forced stop, ref=old [2] Forced stop, ref=0
0-06 GridType [10] 380-440V/50Hz/IT-grid
[11] 380-440V/50Hz/Delta [12] 380-440V/50Hz [20] 440-480V/50Hz/IT-grid [21] 440-480V/50Hz/Delta [22] 440-480V/50Hz [110] 380-440V/60Hz/IT-grid
[111] 380-440V/60Hz/Delta
[112] 380-440V/60Hz [120] 440-480V/60Hz/IT-grid [121] 440-480V/60Hz/Delta [122] 440-480V/60Hz 0-07 Auto DC Braking
[0] O
*[1] On 0-1* Set-up Operations 0-10 Active Set-up *[1] Set-up 1 [2] Set-up 2 [9] Multi Set-up 0-11 Programming Set-up [1] Set-up 1 [2] Set-up 2 *[9] Active Set-up 0-12 Link Setups [0] Not linked *[20] Linked 0-14 Readout: Edit Set-ups / Channel
-2147483647 - 2147483647 *0
0-16 Application Selection *[0] None [1] Simple Process Close Loop [2] Local/Remote [3] Speed Open Loop
[4] Simple Speed Close Loop
[5] Multi Speed [6] OGD LA10 [7] OGD V210
0-2* LCP Display 0-20 Display Line 1.1 Small
[0] None [37] Display Text 1
[38] Display Text 2
[39] Display Text 3 [748] PCD Feed Forward
[953] Probus Warning Word
[1501] Running Hours [1502] kWh Counter
[1600] Control Word [1601] Reference [Unit] *[1602]Reference [%]
[1603] Status Word
[1605] Main Actual Value [%]
[1609] Custom Readout [1610] Power [kW] [1611] Power [hp] [1612] Motor Voltage [1613] Frequency [1614] Motor current
[1615] Frequency [%] [1616] Torque [Nm] [1617] Speed [RPM] [1618] Motor Thermal [1622] Torque [%] [1630] DC Link Voltage
[1633] Brake Energy /2 min
[1634] Heatsink Temp. [1635] Inverter Thermal
[1636] Inv. Nom. Current [1637] Inv. Max. Current
[1638] SL Controller State [1639] Control Card Temp.
[1650] External Reference [1652] Feedback[Unit]
[1653] Digi Pot Reference [1657] Feedback [RPM]
[1660] Digital Input [1661] Terminal 53 Setting [1662] Analog input 53
[1663] Terminal 54 Setting
[1664] Analog input 54 [1665] Analog output 42 [mA]
[1666] Digital Output [1667] Pulse input 29 [Hz]
[1668] Pulse input 33 [Hz]
[1669] Pulse output 27 [Hz]
[1670] Pulse output 29 [Hz]
[1671] Relay output [1672] Counter A [1673] Counter B [1679] Analog output 45 [mA] [1680] Fieldbus CTW 1
[1682] Fieldbus REF 1 [1684] Comm. Option STW
[1685] FC Port CTW 1 [1686] FC Port REF 1 [1690] Alarm Word [1691] Alarm Word 2 [1692] Warning Word [1693] Warning Word 2
[1694] Ext. Status Word
[1695] Ext. Status Word 2
[1697] Alarm Word 3 [1890] Process PID Error
[1891] Process PID Output
[1892] Process PID Clamped Output
[1893] Process PID Gain Scaled Output
[2117] Ext. 1 Reference [Unit]
[2118] Ext. 1 Feedback [Unit]
[2119] Ext. 1 Output [%] [3401] PCD 1 Write For Application
[3402] PCD 2 Write For Application
[3403] PCD 3 Write For Application
[3404] PCD 4 Write For Application [3405] PCD 5 Write For Application
[3406] PCD 6 Write For Application
[3407] PCD 7 Write For Application
[3408] PCD 8 Write For Application
[3409] PCD 9 Write For Application [3410] PCD 10 Write For Application
[3421] PCD 1 Read For Application
[3422] PCD 2 Read For Application
[3423] PCD 3 Read For Application
[3424] PCD 4 Read For Application
[3425] PCD 5 Read For Application
[3426] PCD 6 Read For Application
[3427] PCD 7 Read For Application
[3428] PCD 8 Read For Application [3429] PCD 9 Read For Application
[3430] PCD 10 Read For Application
[3450] Actual Position [3456] Track Error 0-21 Display Line 1.2 Small
Same choices with 0-20
*[1614]Motor current 0-22 Display Line 1.3 Small
Same choices with 0-20
*[1610]Power [kW] 0-23 Display Line 2 Large
Same choices with 0-20
*[1613]Frequency 0-24 Display Line 3 Large
Same choices with 0-20
*[1502]kWh Counter
0-3* LCP Custom Readout
0-30 Custom Readout Unit
[0] None *[1] % [5] PPM [10] 1/min [11] RPM [12] Pulse/s [20] l/s [21] l/min [22] l/h [23] m³/s [24] m³/min [25] m³/h
[30] kg/s [31] kg/min [32] kg/h [33] t/min [34] t/h
[40] m/s [41] m/min [45] m [60] °C [70] mbar
[71] bar [72] Pa [73] kPa [74] m WG [80] kW [120] GPM [121] gal/s [122] gal/min [123] gal/h [124] CFM [127] ft³/h [140] ft/s [141] ft/min [160] °F [170] psi [171] lb/in2 [172] in WG [173] ft WG [180] HP 0-31 Custom Readout Min Value
0 - 999999.99 CustomReadoutUnit *0 CustomReadoutUnit
0-32 Custom Readout Max Value
0.0 - 999999.99 CustomReadoutUnit
*100 CustomReadoutUnit
0-37 Display Text 1
0 - 0 *
0-38 Display Text 2
0 - 0 *
0-39 Display Text 3
0 - 0 *
0-4* LCP Keypad 0-40 [Hand on] Key on LCP [0] Disabled *[1] Enabled
0-42 [Auto on] Key on LCP [0] Disabled *[1] Enabled 0-44 [O/Reset] Key on LCP [0] Disabled *[1] Enabled [7] Enable Reset Only
0-5* Copy/Save 0-50 LCP Copy *[0] No copy [1] All to LCP [2] All from LCP [3] Size indep. from LCP
0-51 Set-up Copy *[0] No copy [1] Copy from setup 1
[2] Copy from setup 2
[9] Copy from Factory setup
0-6* Password
0-60 Main Menu Password
0 - 999 *0
1-** Load and Motor 1-0* General Settings 1-00 Conguration Mode *[0] Open Loop [1] Speed closed loop [2] Torque closed loop
[3] Process Closed Loop
[4] Torque open loop
[6] Surface Winder [7] Extended PID Speed OL
1-01 Motor Control Principle [0] U/f *[1] VVC+ 1-03 Torque Characteristics
*[0] Constant torque [1] Variable Torque [2] Auto Energy Optim. CT 1-06 Clockwise Direction *[0] Normal
[1] Inverse 1-08 Motor Control Bandwidth
[0] High [1] Medium
[2] Low [3] Adaptive 1 [4] Adaptive 2
1-1* Motor Selection 1-10 Motor Construction *[0] Asynchron [1] PM, non salient SPM [3] PM, salient IPM
1-14 Damping Gain
0 - 250 % *120 %
1-15 Low Speed Filter Time Const.
0.01 - 20 s *Size related
1-16 High Speed Filter Time Const.
0.01 - 20 s *Size related
1-17 Voltage lter time const.
0.001 - 1 s *Size related
1-2* Motor Data 1-20 Motor Power [2] 0.12 kW - 0.16 hp [3] 0.18 kW - 0.25 hp
[4] 0.25 kW - 0.33 hp
[5] 0.37 kW - 0.5 hp [6] 0.55 kW - 0.75 hp
[7] 0.75 kW - 1 hp [8] 1.1 kW - 1.5 hp [9] 1.5 kW - 2 hp [10] 2.2 kW - 3 hp [11] 3 kW - 4 hp [12] 3.7 kW - 5 hp [13] 4 kW - 5.4 hp
[14] 5.5 kW - 7.5 hp [15] 7.5 kW - 10 hp [16] 11 kW - 15 hp
[17] 15 kW - 20 hp
Appendix Quick Guide
MG06A702 Danfoss A/S © 03/2017 All rights reserved. 63
