Page #66 background image
[18] 18.5 kW - 25 hp
[19] 22 kW - 30 hp
[20] 30 kW - 40 hp
[21] 37 kW - 50 hp
[22] 45 kW - 60 hp
[23] 55 kW - 75 hp
[24] 75 kW - 100 hp
[25] 90 kW - 120 hp
1-22 Motor Voltage
50 - 1000 V *Size related
1-23 Motor Frequency
20 - 500 Hz *Size related
1-24 Motor Current
0.01 - 1000.00 A *Size related
1-25 Motor Nominal Speed
50 - 60000 RPM *Size related
1-26 Motor Cont. Rated Torque
0.1 - 10000.0 Nm *Size related
1-29 Automatic Motor Adaption (AMA)
*[0] O
[1] Enable Complete AMA
[2] Enable Reduced AMA
1-3* Adv. Motor Data I
1-30 Stator Resistance (Rs)
0.0 - 9999.000 Ohm *Size related
1-31 Rotor Resistance (Rr)
0 - 9999.000 Ohm *Size related
1-33 Stator Leakage Reactance (X1)
0.0 - 9999.000 Ohm *Size related
1-35 Main Reactance (Xh)
0.0 - 9999.00 Ohm *Size related
1-37 d-axis Inductance (Ld)
0 - 65535 mH *Size related
1-38 q-axis Inductance (Lq)
0.000 - 65535 mH *Size related
1-39 Motor Poles
2 - 100 *Size related
1-4* Adv. Motor Data II
1-40 Back EMF at 1000 RPM
1 - 9000 V *Size related
1-42 Motor Cable Length
0 - 100 m *50 m
1-43 Motor Cable Length Feet
0 - 328 ft *164 ft
1-44 d-axis Inductance Sat. (LdSat)
0 - 65535 mH *Size related
1-45 q-axis Inductance Sat. (LqSat)
0 - 65535 mH *Size related
1-46 Position Detection Gain
20 - 200 % *100 %
1-48 Current at Min Inductance for d-axis
20 - 200 % *100 %
1-49 Current at Min Inductance for q-axis
20 - 200 % *100 %
1-5* Load Indep. Setting
1-50 Motor Magnetisation at Zero Speed
0 - 300 % *100 %
1-52 Min Speed Normal Magnetising [Hz]
0.1 - 10.0 Hz *1 Hz
1-55 U/f Characteristic - U
0 - 1000 V *Size related
1-56 U/f Characteristic - F
0 - 500.0 Hz *Size related
1-6* Load Depen. Setting
1-60 Low Speed Load Compensation
0 - 300 % *100 %
1-61 High Speed Load Compensation
0 - 300 % *100 %
1-62 Slip Compensation
-400 - 400.0 % *Size related
1-63 Slip Compensation Time Constant
0.05 - 5 s *0.1 s
1-64 Resonance Dampening
0 - 500 % *100 %
1-65 Resonance Dampening Time Constant
0.001 - 0.05 s *0.005 s
1-66 Min. Current at Low Speed
0 - 120 % *50 %
1-7* Start Adjustments
1-70 Start Mode
*[0] Rotor Detection
[1] Parking
1-71 Start Delay
0 - 10 s *0 s
1-72 Start Function
[0] DC Hold/delay time
*[2] Coast/delay time
[3] Start speed cw
[4] Horizontal operation
[5] VVC+ clockwise
1-73 Flying Start
*[0] Disabled
[1] Enabled
[2] Enabled Always
[3] Enabled Ref. Dir.
[4] Enab. Always Ref. Dir.
1-75 Start Speed [Hz]
0 - 500.0 Hz *Size related
1-76 Start Current
0 - 1000 A *Size related
1-78 Compressor Start Max Speed [Hz]
0 - 500 Hz *0 Hz
1-79 Compressor Start Max Time to Trip
0 - 10 s *5 s
1-8* Stop Adjustments
1-80 Function at Stop
*[0] Coast
[1] DC hold / Motor Preheat
[3] Pre-magnetizing
1-82 Min Speed for Function at Stop [Hz]
0 - 20 Hz *0 Hz
1-88 AC Brake Gain
1.0 - 2.0 *1.4
1-9* Motor Temperature
1-90 Motor Thermal Protection
*[0] No protection
[1] Thermistor warning
[2] Thermistor trip
[3] ETR warning 1
[4] ETR trip 1
[22] ETR Trip - Extended Detection
1-93 Thermistor Source
*[0] None
[1] Analog Input 53
[2] Analog Input 54
[3] Digital input 18
[4] Digital input 19
[5] Digital input 32
[6] Digital input 33
[7] Digital input 31
2-** Brakes
2-0* DC-Brake
2-00 DC Hold/Motor Preheat Current
0 - 160 % *50 %
2-01 DC Brake Current
0 - 150 % *50 %
2-02 DC Braking Time
0 - 60 s *10 s
2-04 DC Brake Cut In Speed
0 - 500 Hz *0 Hz
2-06 Parking Current
0 - 150 % *100 %
2-07 Parking Time
0.1 - 60 s *3 s
2-1* Brake Energy Funct.
2-10 Brake Function
*[0] O
[1] Resistor brake
[2] AC brake
2-11 Brake Resistor (ohm)
0 - 6200 Ohm *Size related
2-12 Brake Power Limit (kW)
0.001 - 2000 kW *Size related
2-14 Brake voltage reduce
0 - 500 V *0 V
2-16 AC Brake, Max current
0 - 160 % *100 %
2-17 Over-voltage Control
*[0] Disabled
[1] Enabled (not at stop)
[2] Enabled
2-19 Over-voltage Gain
0 - 200 % *100 %
2-2* Mechanical Brake
2-20 Release Brake Current
0 - 100 A *0 A
2-22 Activate Brake Speed [Hz]
0 - 400 Hz *0 Hz
2-23 Activate Brake Delay
0 - 5 s *0 s
3-** Reference / Ramps
3-0* Reference Limits
3-00 Reference Range
*[0] Min - Max
[1] -Max - +Max
3-01 Reference/Feedback Unit
[0] None
[1] %
[2] RPM
[3] Hz
[4] Nm
[5] PPM
[10] 1/min
[12] Pulse/s
[20] l/s
[21] l/min
[22] l/h
[23] m³/s
[24] m³/min
[25] m³/h
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[150] lb ft
[160] °F
[170] psi
[171] lb/in2
[172] in WG
[173] ft WG
[180] HP
3-02 Minimum Reference
-4999.0 - 4999 ReferenceFeedbackUnit
*0 ReferenceFeedbackUnit
3-03 Maximum Reference
-4999.0 - 4999 ReferenceFeedbackUnit
*Size related
3-04 Reference Function
*[0] Sum
[1] External/Preset
3-1* References
3-10 Preset Reference
-100 - 100 % *0 %
3-11 Jog Speed [Hz]
0 - 500.0 Hz *5 Hz
3-12 Catch up/slow Down Value
0 - 100 % *0 %
3-14 Preset Relative Reference
-100 - 100 % *0 %
3-15 Reference 1 Source
[0] No function
*[1] Analog Input 53
[2] Analog Input 54
[7] Frequency input 29
[8] Frequency input 33
[11] Local bus reference
[20] Digital pot.meter
[32] Bus PCD
3-16 Reference 2 Source
Same choices with 3-15
*[2] Analog Input 54
3-17 Reference 3 Source
Same choices with 3-15
*[11] Local bus reference
3-18 Relative Scaling Reference Resource
*[0] No function
[1] Analog Input 53
[2] Analog Input 54
[7] Frequency input 29
[8] Frequency input 33
[11] Local bus reference
3-4* Ramp 1
3-40 Ramp 1 Type
*[0] Linear
[2] Sine 2 Ramp
3-41 Ramp 1 Ramp Up Time
0.01 - 3600 s *Size related
3-42 Ramp 1 Ramp Down Time
0.01 - 3600 s *Size related
3-5* Ramp 2
Same content with 3-4*
3-6* Ramp 3
Same content with 3-4*
3-7* Ramp 4
Same content with 3-4*
3-8* Other Ramps
3-80 Jog Ramp Time
0.01 - 3600 s *Size related
3-81 Quick Stop Ramp Time
0.01 - 3600 s *Size related
3-9* Digital Pot.Meter
3-90 Step Size
0.01 - 200 % *0.10 %
3-92 Power Restore
*[0] O
[1] On
3-93 Maximum Limit
-200 - 200 % *100 %
3-94 Minimum Limit
-200 - 200 % *-100 %
Appendix
VLT
®
AutomationDrive FC 360
64 Danfoss A/S © 03/2017 All rights reserved. MG06A702
