10.8 Fastener Tightening Torques
Apply the correct torque when tightening fasteners in the locations that are listed in Table 10.6. Too low or too high torque
when fastening an electrical connection results in a bad electrical connection. To ensure correct torque, use a torque
wrench.
Location Bolt size Torque [Nm (in-lb)]
Mains terminals M10/M12 19 (168)/37 (335)
Motor terminals M10/M12 19 (168)/37 (335)
Ground terminals M8/M10 9.6 (84)/19.1 (169)
Load sharing terminals M10/M12 19 (168)/37 (335)
Relay terminals – 0.5 (4)
Door/panel cover M5 2.3 (20)
Gland plate M5 2.3 (20)
Table 10.6 Fastener Torque Ratings
Specications VLT® AutomationDrive FC 361
64 Danfoss A/S © 06/2018 All rights reserved. MG06I102
