[16-70] Pulse Output #29 [Hz]
[16-71] Pulse Output [bin]
[16-72] Counter A
[16-73] Counter B
[16-75] Analog In X30/11
[16-76] Analog In X30/12
[16-77] Analog In X30/8 [mA]
[16-84] Comm Option STW
[16-85] FC port CTW 1
[16-90] Alarm Word
[16-91] Alarm Word 2
[16-92] Warning Word
[16-93] Warning Word 2
[16-94] Extended Status Word
[16-95] Extended Status Word
2
[16-96] Prev. Maintenance
Word
9-18 Node Address
Range: Function:
126
*
[0 - 126]
Enter the station address in this parameter or alternatively in the hardware switch. In order to adjust the station
address in par. 9-18, the hardware switch must be set to 126 or 127 (i.e. all switches set to ‘on’). Otherwise this
parameter will display the actual setting of the switch.
9-22 Telegram Selection
Option: Function:
Select a standard Profibus telegram configuration for the frequency converter, as an alternative to using the
freely configurable telegrams in par. 9-15 and 9-16.
[1] Standard telegram 1
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108]
*
PPO 8
9-23 Parameters for Signals
Array [1000]
This parameter contains a list of signals available for selection in par. 9-15 and 9-16.
None
[3-02] Minimum Reference
[3-03] Maximum Reference
[3-41] Ramp 1 Ramp Up Time
[3-42] Ramp 1 Ramp Down
Time
[3-51] Ramp 2 Ramp Up Time
3. Parameter Description VLT
®
HVAC Drive Programming Guide
100
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
3
