[3-52] Ramp 2 Ramp Down
Time
[3-80] Jog Ramp Time
[3-81] Quick Stop Ramp Time
[4-11] Motor Speed Low Limit
[RPM]
[4-13] Motor Speed High Limit
[RPM]
[4-16] Torque Limit Motor
Mode
[4-17] Torque Limit Generator
Mode
[5-90] Digital and Relay Bus
Control
[5-93] Pulse Output #27 Bus
Control
[5-95] Pulse Output #29 Bus
Control
[6-53] Terminal 42 Output
Bus Control
[8-90] Bus Jog 1 Speed
[8-91] Bus Jog 2 Speed
[8-94] Bus Feedback 1
[8-95] Bus Feedback 2
[8-96] Bus Feedback 3
[16-00] Control Word
[16-01] Reference [Unit]
[16-02] Reference %
[16-03] Status Word
[16-05] Main Actual Value [%]
[16-09] Custom Readout
[16-10] Power [kW]
[16-11] Power [hp]
[16-12] Motor Voltage
[16-13] Frequency
[16-14] Motor Current
[16-15] Frequency [%]
[16-16] Torque [Nm]
[16-17] Speed [RPM]
[16-18] Thermal Motor Load
[16-30] DC Link Voltage
[16-32] Brake Energy / s
[16-33] Brake Energy / 2 Min
[16-34] Heatsink Temp.
[16-35] Thermal Drive Load
[16-38] SL Controller State
[16-39] Control Card Temp.
[16-50] External Reference
[16-52] Feedback [Unit]
VLT
®
HVAC Drive Programming Guide 3. Parameter Description
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
