7. Extended status word
Events
are logged with value, and time stamp in msec. The time interval between two events depends on how often
events
occur (maximum once every
scan time). Data logging is continuous but if an alarm occurs, the log is saved and the values can be viewed on the display. This feature is useful, for
example when carrying out service following a trip. View the historic log contained in this parameter via the serial communication port or via the display.
15-20 Historic Log: Event
Array [50]
0
*
[0 - 255]
View the event type of the logged events.
15-21 Historic Log: Value
Array [50]
0
*
[0 - 2147483647]
View the value of the logged event. Interpret the event values according to this table:
Digtal input Decimal value. See par. 16-60 for description after converting to
binary value.
Digital output (not monitored in this
SW release)
Decimal value. See par. 16-66 for description after converting to
binary value.
Warning word Decimal value. See par. 16-92 for description.
Alarm word Decimal value. See par. 16-90 for description.
Status word Decimal value. See par. 16-03 for description after converting to
binary value.
Control word Decimal value. See par. 16-00 for description.
Extended status word Decimal value. See par. 16-94 for description.
15-22 Historic Log: Time
Array [50]
0
*
[0 - 2147483647]
View the time at which the logged event occurred. Time is measured in ms since frequency converter start. The
max. value corresponds to approx. 24 days which means that the count will restart at zero after this time period.
3.15.5. Alarm Log, 15-3*
Parameters in this group are array parameters, where up to 10 fault logs can be viewed. [0] is the most recent logged data, and [9] the oldest. Error
codes, values, and time stamp can be viewed for all logged data.
15-30 Alarm Log: Error Code
Array [10]
0
*
[0 - 255]
View the error code and look up its meaning in the
Troubleshooting
chapter.
15-31 Alarm Log: Value
Array [10]
0
*
[-32767 - 32767]
View an extra description of the error. This parameter is mostly used in combination with alarm 38 ‘internal fault’.
VLT
®
HVAC Drive Programming Guide 3. Parameter Description
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
137
3
