16-30 DC Link Voltage
Range: Function:
0V
*
[0 - 10000 V]
View a measured value. The value is filtered with an 30 ms time constant.
16-32 Brake Energy /s
Range: Function:
0 kW
*
[0 to 675.000 kW]
View the brake power transmitted to an external brake resistor, stated as an instantaneous value.
16-33 Brake Energy /2 min
Range: Function:
0.000kW
*
[0.000 - 500.000 kW]
View the brake power transmitted to an external brake resistor. The mean power is calculated on an average
basis for the most recent 120 seconds.
16-34 Heatsink Temp.
Range: Function:
0°C
*
[0 - 255 °C]
View the frequency converter heatsink temperature. The cut-out limit is 90 ± 5 °C, and the motor cuts back in
at 60 ± 5 °C.
16-35 Inverter Thermal
Range: Function:
0 %
*
[0 - 100 %]
View the percentage load on the inverter.
16-36 Inv. Nom. Current
Range: Function:
A
*
[0.01 - 10000 A]
View the inverter nominal current, which should match the nameplate data on the connected motor. The data
are used for calculation of torque, motor protection, etc.
16-37 Inv. Max. Current
Range: Function:
Size dependent
*
[0.01 to 10000 A]
View the inverter maximum current, which should match the nameplate data on the connected motor. The data
are used for calculation of torque, motor protection, etc.
16-38 SL Controller State
Range: Function:
0
*
[0 - 100]
View the state of the event under execution by the SL controller.
16-39 Control Card Temp.
Range: Function:
0°C
*
[0 - 100 °C]
View the temperature on the control card, stated in °C.
16-40 Logging Buffer Full
Option: Function:
View whether the logging buffer is full (see par. 15-1*). The logging buffer will never be full when
par. 15-13
Logging Mode
is set to
Log always
[0].
[0]
*
No
[1] Yes
VLT
®
HVAC Drive Programming Guide 3. Parameter Description
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
143
3
