3.16.5. 16-5* Ref. & Feedb.
Parameters for reporting the reference and feedback input.
16-50 External Reference
Range: Function:
0.0 * [0.0 - 0.0 ]
View the total reference, the sum of digital, analog, preset, bus and freeze references, plus catch-up and slow-
down.
16-52 Feedback [Unit]
Range: Function:
0.0 * [0.0 - 0.0]
View value of resulting feedback value after processing of Feedback 1-3 (see par. 16-54, 16-55 and 16-56) in
the feedback manager.
See par. 20-0*
Feedback .
The value is limited by settings in par. 3-02 and 3-03. Units as set in par. 20-12.
16-53 Digi Pot Reference
Range: Function:
0.0 [0.0 - 0.0] View the contribution of the Digital Potentiometer to the actual reference.
16-54 Feedback 1 [Unit]
Range: Function:
[0.0 - 0.0] View value of Feedback 1, see par. 20-0* Feedback .
Value is limited by settings in par. 3-02 and 3-03. Units as set in par. 20-12.
16-55 Feedback 2 [Unit]
Range: Function:
[0.0 - 0.0] View value of Feedback 2, see par. 20-0* Feedback .
Value is limited by settings in par. 3-02 and 3-03. Units as set in par. 20-12.
16-56 Feedback 3[Unit]
Range: Function:
[0.0 - 0.0] View value of Feedback 3, see par. 20-0* Feedback .
Value is limited by settings in par. 3-02 and 3-03. Units as set in par. 20-12.
16-58 PID Output
Option: Function:
[0 %] 0 - 100 % This parameter returns the Drive Closed Loop PID controller output value in percent.
3.16.6. 16-6* Inputs and Outputs
Parameters for reporting the digital and analog IO ports.
3. Parameter Description VLT
®
HVAC Drive Programming Guide
144 MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
3
