16-60 Digital Input
Range: Function:
0 * [0 - 63]
View the signal states from the active digital inputs. Example: Input 18 corresponds to bit no. 5, ‘0’ = no signal,
‘1’ = connected signal. Bit 6 works in the opposite way, on = '0', off = '1' (safe stop input).
Bit 0
Digital input term. 33
Bit 1 Digital input term. 32
Bit 2 Digital input term. 29
Bit 3 Digital input term. 27
Bit 4 Digital input term. 19
Bit 5 Digital input term. 18
Bit 6 Digital input term. 37
Bit 7 Digital input GP I/O term. X30/4
Bit 8 Digital input GP I/O term. X30/3
Bit 9 Digital input GP I/O term. X30/2
Bit 10-63 Reserved for future terminals
16-61 Terminal 53 Switch Setting
Option: Function:
View the setting of input terminal 53. Current = 0; Voltage = 1.
[0]
*
Current
[1] Voltage
16-62 Analog Input 53
Range: Function:
0.000 * [0.000 - 0.000]
View the actual value at input 53.
16-63 Terminal 54 Switch Setting
Option: Function:
View the setting of input terminal 54. Current = 0; Voltage = 1.
[0]
*
Current
[1] Voltage
16-64 Analog Input 54
Range: Function:
0.000 * [0.000 - 0.000]
View the actual value at input 54.
16-65 Analog Output 42 [mA]
Range: Function:
0.000 * [0.000 - 0.000]
View the actual value at output 42 in mA. The value shown reflects the selection in par. 06-50.
16-66 Digital Output [bin]
Range: Function:
0 * [0 - 3]
View the binary value of all digital outputs.
16-67 Freq. Input 29 [Hz]
Range: Function:
0 * [0 - 0]
View the actual frequency rate on terminal 29.
VLT
®
HVAC Drive Programming Guide 3. Parameter Description
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark 145
3
