0-14 Readout: Prog. Set-ups / Channel
Range: Function:
AAA.AAA.AAA
*
[0 - FFF.FFF.FFF]
View the setting of par. 0-11
Edit Set-up
for each of the four different communication channels. When the number
is displayed in hex, as it is in the LCP, each number represents one channel.
Numbers 1-4 represent a set-up number; ‘F’ means factory setting; and ‘A’ means active set-up. The channels
are, from right to left: LCP, FC-bus, USB, HPFB1.5.
Example: The number AAAAAA21h means that the FC bus selected Set-up 2 in par. 0-11, the LCP selected Set-
up 1 and all others used the active set-up.
3.2.4. 0-2* LCP Display
Define the variables displayed in the Graphical Local Control Panel.
NB!
Please refer to parameters 0-37, 0-38 and 0-39 for information on how to write display texts
0-20 Display Line 1.1 Small
Option: Function:
Select a variable for display in line 1, left position.
[0] None No display value selected
[37] Display Text 1 Enables an individual text string to be written, for display in the LCP or to be read via serial communication.
[38] Display Text 2 Enables an individual text string to be written, for display in the LCP or to be read via serial communication.
[39] Display Text 3 Enables an individual text string to be written, for display in the LCP or to be read via serial communication.
[89] Date and Time Readout Displays the current date and time.
[953] Profibus Warning Word Displays Profibus communication warnings.
[1005] Readout Transmit Error
Counter
View the number of CAN control transmission errors since the last power-up.
[1006] Readout Receive Error
Counter
View the number of CAN control receipt errors since the last power-up.
[1007] Readout Bus Off
Counter
View the number of Bus Off events since the last power-up.
[1013] Warning Parameter View a DeviceNet-specific warning word. One separate bit is assigned to every warning.
[1115] LON Warning Word Shows the LON-specific warnings.
[1117] XIF Revision Shows the version of the external interface file of the Neuron C chip on the LON option.
[1118] LON Works Revision Shows the software version of the application program of the Neuron C chip on the LON option.
[1501] Running Hours View the number of running hours of the motor.
[1502] kWh Counter View the mains power consumption in kWh.
[1600] Control Word View the Control Word sent from the frequency converter via the serial communication port in hex code.
[1601] Reference [Unit] Total reference (sum of digital/analog/preset/bus/freeze ref./catch up and slow-down) in selected unit.
[1602]
*
Reference % Total reference (sum of digital/analog/preset/bus/freeze ref./catch up and slow-down) in percent.
[1603] Status Word Present status word
[1605] Main Actual Value [%] One or more warnings in a Hex code
[1609] Custom Readout View the user-defined readouts as defined in par. 0-30, par. 0-31 and par. 0-32.
[1610] Power [kW] Actual power consumed by the motor in kW.
[1611] Power [hp] Actual power consumed by the motor in HP.
[1612] Motor Voltage Voltage supplied to the motor.
[1613] Motor Frequency Motor frequency, i.e. the output frequency from the frequency converter in Hz.
[1614] Motor Current Phase current of the motor measured as effective value.
3. Parameter Description VLT
®
HVAC Drive Programming Guide
28
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
3
