5-13 Terminal 29 Digital Input
Option: Function:
[14]
*
Jog Same options and functions as par. 5-1*
Digital Inputs
.
5-14 Terminal 32 Digital Input
Option: Function:
[0]
*
No Operation Same options and functions as par. 5-1*
Digital Inputs
, except for
Pulse input
.
5-15 Terminal 33 Digital Input
Option: Function:
[0]
*
No Operation Same options and functions as par. 5-1*
Digital Inputs
.
5-16 Terminal X30/2 Digital Input
Option: Function:
[0]
*
No operation This parameter is active when option module MCB 101 is installed in the frequency converter.
It has the same options and functions as par. 5-1
Digital Inputs
, except for
Pulse input
[32].
5-17 Terminal X30/3 Digital Input
Option: Function:
[0]
*
No operation This parameter is active when option module MCB 101 is installed in the frequency converter.
It has the same options and functions as par. 5-1
Digital Inputs
, except for
Pulse input
[32].
5-18 Terminal X30/4 Digital Input
Option: Function:
[0]
*
No operation This parameter is active when option module MCB 101 is installed in the frequency converter.
It has the same options and functions as par. 5-1
Digital Inputs
, except for
Pulse input
[32].
3.7.5. 5-3* Digital Outputs
Parameters for configuring the output functions for the output terminals. The 2 solid-state digital outputs are common for terminals 27 and 29. Set the
I/O function for terminal 27 in par. 5-01
Terminal 27 Mode
, and set the I/O function for terminal 29 in par. 5-02
Terminal 29 Mode
. These parameters
cannot be adjusted while the motor is running.
The digital outputs can be programmed with these functions:
[0] No operation
Default for all digital outputs and relay outputs
[1] Control ready The control board receives supply voltage.
[2] Drive ready The frequency converter is ready for operation and applies a supply signal on the control board.
[3] Drive ready / remote
control
The frequency converter is ready for operation and is in Auto On mode.
[4] Stand-by / no warning The frequency converter is ready for operation. No start or stop command is been given (start/disable). There
are no warnings.
[5] Running The motor is running.
[6] Running / no warning The output speed is higher than the speed set in par. 1-81
Min Speed for Function at Stop [RPM]
. The motor is
running and there are no warnings.
[8] Run on reference / no
warning
The motor runs at reference speed.
[9] Alarm An alarm activates the output. There are no warnings.
[10] Alarm or warning An alarm or a warning activates the output.
[11] At torque limit The torque limit set in par. 4-16 or par. 1-17 has been exceeded.
VLT
®
HVAC Drive Programming Guide 3. Parameter Description
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
69
3
