[12] Out of current range The motor current is outside the range set in par. 4-18.
[13] Below current, low The motor current is lower than set in par. 4-50.
[14] Above current, high The motor current is higher than set in par. 4-51.
[15] Out of speed range The output speed is outside the range set in par. 4-52 and 4-53.
[16] Below speed, low The output speed is lower than the setting in par. 4-52.
[17] Above speed, high The output speed is higher than the setting in par. 4-53.
[18] Out of feedback range The feedback is outside the range set in par. 4-56 and 4-57.
[19] Below feedback low The feedback is below the limit set in par. 4-56 Warning Feedback Low.
[20] Above feedback high The feedback is above the limit set in par. 4-57
Warning Feedback High
.
[21] Thermal warning The thermal warning turns on when the temperature exceeds the limit in the motor, the frequency converter,
the brake resistor, or the thermistor.
[25] Reverse
Reversing. Logic ‘1’ =
relay activated, 24 V DC when CW rotation of the motor. Logic ‘0’ = relay not activated,
no signal, when CCW rotation of the motor.
[26] Bus OK Active communication (no time-out) via the serial communication port.
[27] Torque limit and stop Use in performing a coasting stop and in torque limit condition. If the frequency converter has received a stop
signal and is at the torque limit, the signal is Logic ‘0’.
[28] Brake, no warning The brake is active and there are no warnings.
[29] Brake ready, no fault The brake is ready for operation and there are no faults.
[30] Brake fault (IGBT) The output is Logic ‘1’ when the brake IGBT is short-circuited. Use this function to protect the frequency con-
verter if there is a fault on the brake modules. Use the output/relay to cut out the main voltage from the
frequency converter.
[35] External Interlock External Interlock function has been activated via one of the digital inputs.
[40] Out of ref range
[41] Below reference low
[42] Above reference high
[45] Bus Ctrl
[46] Bus Ctrl 1 if timeout
[47] Bus Ctrl 0 if timeout
[55] Pulse output
[60] Comparator 0 See par. group 13-1*. If Comparator 0 is evaluated as TRUE, the output will go high. Otherwise, it will be low.
[61] Comparator 1 See par. group 13-1*. If Comparator 2 is evaluated as TRUE, the output will go high. Otherwise, it will be low.
[62] Comparator 2 See par. group 13-1*. If Comparator 2 is evaluated as TRUE, the output will go high. Otherwise, it will be low.
[63] Comparator 3 See par. group 13-1*. If Comparator 3 is evaluated as TRUE, the output will go high. Otherwise, it will be low.
[64] Comparator 4 See par. group 13-1*. If Comparator 4 is evaluated as TRUE, the output will go high. Otherwise, it will be low.
[65] Comparator 5 See par. group 13-1*. If Comparator 5 is evaluated as TRUE, the output will go high. Otherwise, it will be low.
[70] Logic Rule 0 See par. group 13-4*. If Logic Rule 0 is evaluated as TRUE, the output will go high. Otherwise, it will be low.
[71] Logic Rule 1 See par. group 13-4*. If Logic Rule 1 is evaluated as TRUE, the output will go high. Otherwise, it will be low.
[72] Logic Rule 2 See par. group 13-4*. If Logic Rule 2 is evaluated as TRUE, the output will go high. Otherwise, it will be low.
[73] Logic Rule 3 See par. group 13-4*. If Logic Rule 3 is evaluated as TRUE, the output will go high. Otherwise, it will be low.
[74] Logic Rule 4 See par. group 13-4*. If Logic Rule 4 is evaluated as TRUE, the output will go high. Otherwise, it will be low.
[75] Logic Rule 5 See par. group 13-4*. If Logic Rule 5 is evaluated as TRUE, the output will go high. Otherwise, it will be low.
[80] SL Digital Output A See par. 13-52
SL Control Action
. The input will go high whenever the Smart Logic Action [38]
Set dig. out. A
high
is executed. The input will go low whenever the Smart Logic Action [32] Set dig. out. A low is executed.
[81] SL Digital Output B See par. 13-52
SL Control Action
. The input will go high whenever the Smart Logic Action [39]
Set dig. out.
Bhigh
is executed. The input will go low whenever the Smart Logic Action [33]
Set dig. out. B low
is executed.
[82] SL Digital Output C See par. 13-52
SL Control Action
. The input will go high whenever the Smart Logic Action [40]
Set dig. out. C
high
is executed. The input will go low whenever the Smart Logic Action [34]
Set dig. out. C low
is executed.
[83] SL Digital Output D See par. 13-52
SL Control Action
. The input will go high whenever the Smart Logic Action [41]
Set dig. out. D
high is executed. The input will go low whenever the Smart Logic Action [35]
Set dig. out. D low
is executed.
3. Parameter Description VLT
®
HVAC Drive Programming Guide
70
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
3
