3.8.6. 6-4* Analog Input 4 (MCB 101)
Parameter group for configuring the scale and limits for analog input 4 (X30/12) placed on option module MCB 101.
6-40 Term. X30/12 Low Voltage
Range: Function:
0.7 V * [0 to par. 6-41]
Sets the analog input scaling value to correspond to the low reference/feedback value set in par. 6-44.
6-41 Term. X30/12 High Voltage
Range: Function:
10.0V * [Par. 6-40 to 10.0 V]
Sets the analog input scaling value to correspond to the high reference/feedback value set in par. 6-45.
6-44 Term. X30/12 Low Ref./Feedb. Value
Range: Function:
Sets the analog input scaling value to correspond to the low voltage value set in par. 6-40.
0.000 Unit
* [-1000000.000 to par.
6-45]
6-45 Term. X30/12 High Ref./Feedb. Value
Range: Function:
1500.000 Unit * [Par. 6-44 to
1000000.000]
Sets the analog input scaling value to correspond to the high voltage value set in par. 6-41.
6-46 Term. X30/12 Filter Time Constant
Range: Function:
0.001s * [0.001 - 10.000 s]
A 1
st
order digital low pass filter time constant for suppressing electrical noise on terminal X30/12.
Par. 6-46 cannot be changed while the motor is running.
6-47 Term. X30/12 Live Zero
Option: Function:
This parameter makes it possible to disable the Live Zero monitoring. E.g. to be used if the analog outputs are
used as part of a decentral I/O system (e.g. when not part of any frequency converter related control functions,
but feeding a Building Management System with data)
[0]
*
Disabled
[1] Enabled
3.8.7. 6-5* Analog Output 1
Parameters for configuring the scaling and limits for analog output 1, i.e. Terminal 42. Analog outputs are current outputs: 0/4 – 20 mA. Common terminal
(terminal 39) is the same terminal and has the same electrical potential for analog common and digital common connection. Resolution on analog output
is 12 bit.
6-50 Terminal 42 Output
Option: Function:
Select the function of Terminal 42 as an analog current output.
[0] No operation
[100]
*
Output frequency : 0 - 100 Hz
[101] Reference : Minimum reference - Maximum reference
[102] Feedback : -200% to +200% of par. 2-14
[103] Motor current : 0 - Inverter Max. Current (par. 16-37)
3. Parameter Description VLT
®
HVAC Drive Programming Guide
84 MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
