[104] Torque rel to lim : 0 - Torque limit (par. 4-16)
[105] Torque rel to rated : 0 - Motor rated torque
[106] Power : 0 - Motor rated power
[107] Speed : 0 - Speed High Limit (par. 4-13 and par. 4-14)
[113] Ext. closed loop 1 : 0 - 100%
[114] Ext. closed loop 2 : 0 - 100%
[115] Ext. closed loop 3 : 0 - 100%
[130] Output freq. 4-20mA :0 - 100 Hz
[131] Reference 4-20mA :Minimum Reference - Maximum Reference
[132] Feedback 4-20mA :-200% to +200% of par. 2-14
[133] Motor cur. 4-20 mA :0 - Inverter Max. Current (par. 16-37)
[134] Torque % lim. 4-20 mA :0 - Torque limit (par. 4-16)
[135] Torque % nom 4-20
mA
:0 - Motor rated torque
[136] Power 4-20 mA :0 - Motor rated power
[137] Speed 4-20 mA :0 - Speed High Limit (par. 4-13 and par. 4-14)
[139] Bus ctrl. 0-20 mA :0 - 100%
[140] Bus ctrl. 4-20 mA : 0 - 100%
[141] Bus ctrl. 0-20 mA, time-
out
: 0 - 100%
[142] Bus ctrl. 4-20 mA, time-
out
: 0 - 100%
[143] Ext. Closed Loop 1,
4-20 mA
: 0 - 100%
[144] Ext. Closed Loop 2,
4-20 mA
: 0 - 100%
[145] Ext. Closed Loop 3,
4-20 mA
: 0 - 100%
NB!
Values for setting the Minimum Reference is found in par. 3-02
Open Loop
and par. 20-13
Closed Loop
- values for Maximum Reference is found in
par. 3-03
Open Loop
and par. 20-14
Closed Loop
.
6-51 Terminal 42 Output Min Scale
Range: Function:
See the drawing below for details.
0%
*
[0 – 200%]
Scale for the minimum output (0 or 4 mA) of the analogue signal at terminal 42.
Set the value to be the percentage of the full range of the variable selected in par. 6-50.
6-52 Terminal 42 Output Max Scale
Range: Function:
100%
*
[0 – 200%]
Scale for the maximum output (20 mA) of the analog signal at terminal 42.
Set the value to be the percentage of the full range of the variable selected in par. 6-50.
VLT
®
HVAC Drive Programming Guide 3. Parameter Description
MG.11.C5.02 - VLT
®
is a registered Danfoss trademark
85
