Danfoss VLT Micro Drive FC 51 Series - Control Terminals

For EMC correct installation, use optional de-coupling plate, see chapter
Options for frequency converter .
Illustration 3.5: Frequency converter with de-coupling plate
3.4 Control Terminals
3.4.1 Access to Control Terminals
All control cable terminals are located underneath the terminal cover in
front of the frequency converter. Remove the terminal cover using a
screwdriver.
Illustration 3.6: Removing terminal cover.
NB!
See back of terminal cover for outlines of control terminals and switches.
