Danfoss VLT Micro Drive FC 51 Series User Manual

Normal overload 150% for 1 minute Frequency converter Typical Shaft Output [kW]
P0K37
0.37
P0K75
0.75
P1K5
1.5
P2K2
2.2
P3K0
3.0
P4K0
4.0
P5K5
5.5
P7K5
7.5
Typical Shaft Output [HP] 0.5 1 2 3 4 5 7.5 10 IP 20 Frame M1 Frame M1 Frame M2 Frame M2 Frame M3 Frame M3 Frame M3 Frame M3 Output current
Continuous (3 x 380-440 V) [A] 1.2 2.2 3.7 5.3 7.2 9.0 12.0 15.5 Intermittent (3 x 380-440 V) [A] 1.8 3.3 5.6 8.0 10.8 13.7 18.0 23.5 Continuous (3 x 440-480 V) [A] 1.1 2.1 3.4 4.8 6.3 8.2 11.0 14.0
Intermittent (3 x 440-480 V) [A] 1.7 3.2 5.1 7.2 9.5 12.3 16.5 21.3
Max. cable size: (mains, motor) [mm
2
/ AWG]
4/10
Max. input current
Continuous (3 x 380-440 V ) [A] 1.9 3.5 5.9 8.5 11.5 14.4 19.2 24.8 Intermittent (3 x 380-440 V ) [A] 2.6 4.7 8.7 12.6 16.8 20.2 27.4 36.3
Continuous (3 x 440-480 V ) [A] 1.7 3.0 5.1 7.3 9.9 12.4 16.6 21.4
Intermittent (3 x 440-480 V ) [A] 2.3 4.0 7.5 10.8 14.4 17.5 23.6 30.1
Max. pre-fuses [A]
See Section
Fuses
Environment Estimated power loss at rated load [W] Best case/Typical
1)
18.5/25.5 28.5/43.5 41.5/56.5 57.5/81.5 75.0/101.6 98.5/133.5 131.0/166.8 175.0/217.5
Weight enclosure IP20 [kg] 1.1 1.1 1.6 1.6 3.0 3.0 3.0 3.0
Efficiency Best case/Typical
1)
96.8/95.5 97.4/96.0 98.0/97.2 97.9/97.1 97.2/98.0 97.3/98.0 97.5/98.0 97.5/98.0
1. Power loss at rated load conditions.
Table 8.1: Mains supply 3 x 380 - 480 VAC
