Danfoss VLT Micro Drive FC 51 User Manual

•
•
1.
2.
3.
4.
5.
6.
7.
8.
9.
1.
2.
3.
4.
5.
6.
7.
8.
9.
-
Pressing [OK] for more than 1 s enters Adjust mode. In Adjust mode, it is possible to make fast adjustment by pressing [▵] [▿] com-
bined with [OK].
Press [▵] [▿] to change value. Press [OK] to shift between digits quickly.
To exit Adjust mode, press [OK] more than 1 s again with changes saving or press [Back] without changes saving.
Operation keys
A yellow indicator light above the operation keys indicates the active key.
[Hand On]: Starts the motor and enables control of the drive via the LCP.
[O/Reset]: The motor stops. If in alarm mode, the motor resets.
[Auto On]: The drive is controlled either via control terminals or serial communication.
[Potentiometer] (LCP12): The potentiometer works in 2 ways depending on the mode in which the drive is running.
In auto-on mode, the potentiometer acts as an extra programmable analog input.
In hand-on mode, the potentiometer controls local reference.
4.2 Programming on Automatic Motor Tuning (AMT)
Run AMT to optimize compatibility between the drive and the motor in VVC
+
mode.
The drive builds a mathematical model of the motor for regulating output motor current thus enhancing motor performance.
Run this procedure on a cold motor for best results. To run AMT, use the numeric LCP (NLCP). There are 2 AMT modes for drives.
N O T I C E
In mode 2, the rotor rotates during the AMT progress.
Do not add any load on the motor in this AMT progress.
4.2.1 Mode 1
Procedure
Enter the main menu.
Go to parameter group 1-** Load and Motor.
Press [OK].
Set motor parameters using nameplate data for parameter group 1-2* Motor Data.
Go to parameter 1-29 Automatic Motor Tuning (AMT).
Press [OK].
Select [2] Enable AMT.
Press [OK].
The test runs automatically and indicates when it is complete.
4.2.2 Mode 2
Procedure
Enter the main menu.
Go to parameter group 1-** Load and Motor.
Press [OK].
Set motor parameters using nameplate data for parameter group 1-2* Motor Data.
Go to parameter 1-29 Automatic Motor Tuning (AMT).
Press [OK].
Select [3] Complete AMT with Rotating motor.
Press [OK].
The test runs automatically and indicates when it is complete.
AQ348848915086en-000101 / 130R094318 | Danfoss A/S © 2020.09
Programming
VLT® Micro Drive FC 51
Operating Guide
