Maximum terminal load (DC-1)
(1)
on 01–02 (NO) (Resistive load)
Maximum terminal load (DC-13)
(1)
on 01–02 (NO) (Inductive load)
Maximum terminal load (AC-1)
(1)
on 01–03 (NC) (Resistive load)
Maximum terminal load (AC-15)
(1)
on 01–03 (NC) (Inductive load
@ cosφ 0.4)
Maximum terminal load (DC-1)
(1)
on 01–03 (NC) (Resistive load)
Minimum terminal load on 01–03 (NC), 01–02 (NO)
24 V DC 10 mA, 24 V AC 20 mA
Environment according to EN 60664-1
Overvoltage category III/pollution degree 2
1
IEC 60947 part 4 and 5.
8.11 Control Card, +10 V DC Output
N O T I C E
All inputs, outputs, circuits, DC supplies, and relay contacts are galvanically isolated from the supply voltage (PELV) and other
high-voltage terminals.
8.12 Surroundings
Enclosure protection rating
Maximum relative humidity
5–95% (IEC 60721-3-3; Class 3K3 (non-condensing) during opera-
tion)
Aggressive environment (IEC 60721-3-3), coated
Test method according to IEC 60068-2-43 H2S (10 days)
Minimum ambient temperature during full-scale operation
Minimum ambient temperature at reduced performance
Temperature during storage/transport
-25 to +65/70 °C (-13 to +149/158 °F)
Maximum altitude above sea level without derating
(1)
Maximum altitude above sea level with derating
(1)
1
Refer to chapter Special Conditions for:
Derating for high ambient temperature.
Derating for high altitude.
2
Determined according to EN 50598-2 at:
Rated load.
90% rated frequency.
Switching frequency factory setting.
Switching pattern factory setting.
