Danfoss VLT Micro Drive FC 51 User Manual

5 Parameter Overview
5.1 Parameter List
Table 6: Parameter List
0-** Operation/Display
0-0* Basic Settings
0-03 Regional Settings
*[0] International
[1] US
0-04 Oper. State at Power-up
(Hand)
[0] Resume
*[1] Forced stop, ref=old
[2] Forced stop, ref=0
0-1* Set-up Handling
0-10 Active Set-up
*[1] Set-up 1
[2] Set-up 2
[9] Multi Set-up
0-11 Edit Set-up
*[1] Set-up 1
[2] Set-up 2
[9] Active Set-up
0-12 Link Set-ups
[0] Not Linked
*[20] Linked
0-31 Custom Readout Min
Scale
0.00–9999.00 * 0.00
0-32 Custom Readout Max
Scale
0.00–9999.00 * 100.0
0-4* LCP Keypad
0-40 [Hand on] Key on LCP
[0] Disabled
*[1] Enabled
0-41 [O / Reset] Key on LCP
[0] Disable All
*[1] Enable All
[2] Enable Reset Only
0-42 [Auto on] Key on LCP
[0] Disabled
*[1] Enabled
0-5* Copy/Save
0-50 LCP Copy
*[0] No copy
[1] All to LCP
[2] All from LCP
[3] Size indep. from LCP
0-51 Set-up Copy
*[0] No copy
[1] Copy from set-up 1
[2] Copy from set-up 2
[9] Copy from Factory set-up
0-6* Password
0-60 (Main) Menu Password
0–999 *0
0-61 Access to Main/Quick
Menu w/o Password
*[0] Full access
[1] LCP:Read Only
[2] LCP:No Access
1-** Load/Motor
1-0* General Settings
1-00 Conguration Mode
*[0] Speed open loop
[3] Process
1-01 Motor Control Principle
[0] U/f
*[1] VVC+
1-03 Torque Characteristics
*[0] Constant torque
[2] Automatic Energy Optim.
1-05 Local Mode Congura-
tion
[0] Speed Open Loop
*[2] As cong in par. 1-00
1-2* Motor Data
1-20 Motor Power [kW] [hp]
[1] 0.09 kW/0.12 hp
[2] 0.12 kW/0.16 hp
[3] 0.18 kW/0.25 hp
[4] 0.25 kW/0.33 hp
[5] 0.37 kW/0.50 hp
[6] 0.55 kW/0.75 hp
[7] 0.75 kW/1.00 hp
[8] 1.10 kW/1.50 hp
[9] 1.50 kW/2.00 hp
[10] 2.20 kW/3.00 hp
[11] 3.00 kW/4.00 hp
[12] 3.70 kW/5.00 hp
[13] 4.00 kW/5.40 hp
[14] 5.50 kW/7.50 hp
[15] 7.50 kW/10.00 hp
[16] 11.00 kW/15.00 hp
[17] 15.00 kW/20.00 hp
[18] 18.50 kW/25.00 hp
[19] 22.00 kW/29.50 hp
[20] 30.00 kW/40.00 hp
1-22 Motor Voltage
50-999 V *230–400 V
1-23 Motor Frequency
20–400 Hz *50 Hz
1-24 Motor Current
0.01–100.00 A *Motortype
dep.
1-25 Motor Nominal Speed
100–9999 rpm *Motortype
dep.
1-29 Automatic Motor Tuning
(AMT)
*[0] O
[2] Enable AMT
[3] Complete AMT with Rotat-
ing motor
1-3* Adv. Motor Data
1-30 Stator Resistance (Rs)
[Ohm] * Dep. on motor data
1-33 Stator Leakage Reac-
tance (X1)
[Ohm] * Dep. on motor data
1-35 Main Reactance (Xh)
[Ohm] * Dep. on motor data
1-5* Load Indep. Setting
1-50 Motor Magnetisation at 0
Speed
0–300% *100%
1-52 Min Speed Norm. Mag-
net. [Hz]
0.0–10.0 Hz *0.0Hz
1-55 U/f Characteristic - U
0-999.9 V
1-56 U/f Characteristic - F
0-400 Hz
1-6* Load Depen. Setting
1-60 Low Speed Load Com-
pensation
0–199% *100%
1-61 High Speed Load Com-
pensation
0–199%*100%
1-62 Slip Compensation
-400–399% *100%
1-63 Slip Compensation Time
Constant
0.05–5.00 s *0.10 s
1-7* Start Adjustments
1-71 Start Delay
0.0–10.0 s *0.0 s
1-72 Start Function
[0] DC hold/delay time
[1] DC brake/delay time
*[2] Coast/delay time
1-73 Flying Start
*[0] Disabled
[1] Enabled
1-8* Stop Adjustments
1-80 Function at Stop
*[0] Coast
[1] DC hold
1-82 Min Speed for Funct. at
Stop [Hz]
0.0–20.0 Hz *0.0 Hz
1-9*Motor Temperature
1-90 Motor Thermal Protec-
tion
*[0] No protection
[1] Thermistor warning
[2] Thermistor trip
[3] Etr warning
[4] Etr trip
1-93 Thermistor Resource
*[0] None
[1] Analog input 53
[6] Digital input 29
2-** Brakes
2-0* DC-Brake
2-00 DC Hold Current
0–150% *50%
2-01 DC Brake Current
0–150% *50%
2-02 DC Braking Time
0.0–60.0 s *10.0 s
2-04 DC Brake Cut In Speed
0.0–400.0 Hz *0.0Hz
2-1* Brake Energy Funct.
2-10 Brake Function
*[0] O
[1] Resistor brake
[2] AC brake
2-11 Brake Resistor (ohm)
Min/Max/default: Powersize
dep.
AQ348848915086en-000101 / 130R0943 | 19Danfoss A/S © 2020.09
Parameter Overview
VLT® Micro Drive FC 51
Operating Guide
