Page #20 background image
Table 7: Parameter List
2-14 Brake Voltage reduce
0 - Powersize dep.* 0
2-16 AC Brake, Max current
0-150% *100%
2-17 Overvoltage Control
*[0] Disabled
[1] Enabled (not at stop)
[2] Enabled
2-2* Mechanical Brake
2-20 Release Brake Current
0.00–100.0 A *0.00 A
2-22 Activate Brake Speed
[Hz]
0.0–400.0 Hz *0.0 Hz
3-** Reference / Ramps
3-0* Reference Limits
3-00 Reference Range
*[0] Min - Max
[1] -Max - +Max
3-02 Minimum Reference
-4999–4999 *0.000
3-03 Maximum Reference
-4999–4999 *50.00
3-1* References
3-10 Preset Reference
-100.0–100.0% *0.00%
3-11 Jog Speed [Hz]
0.0–400.0 Hz *5.0 Hz
3-12 Catch up/slow Down Val-
ue
0.00–100.0% * 0.00%
3-14 Preset Relative Reference
-100.0–100.0% *0.00%
3-15 Reference Resource 1
[0] No function
*[1] Analog Input 53
[2] Analog input 60
[8] Pulse input 33
[11] Local bus ref
[21] LCP Potentiometer
3-16 Reference Resource 2
[0] No function
[1] Analog in 53
*[2] Analog in 60
[8] Pulse input 33
*[11] Local bus reference
[21] LCP Potentiometer
3-17 Reference Resource 3
[0] No function
[1] Analog Input 53
[2] Analog input 60
[8] Pulse input 33
*[11] Local bus ref
[21] LCP Potentiometer
3-18 Relative Scaling Ref. Re-
source
*[0] No function
[1] Analog Input 53
[2] Analog input 60
[8] Pulse input 33
[11] Local bus ref
[21] LCP Potentiometer
3-4* Ramp 1
3-40 Ramp 1 Type
*[0] Linear
[2] Sine2 ramp
3-41 Ramp 1 Ramp up Time
0.05–3600 s *3.00 s (10.00 s)
(1)
3-42 Ramp 1 Ramp Down
Time
0.05–3600 s *3.00s (10.00s)
(1)
3-5* Ramp 2
3-50 Ramp 2 Type
*[0] Linear
[2] Sine2 ramp
3-51 Ramp 2 Ramp up Time
0.05–3600 s *3.00s (10.00s)
(1)
3-52 Ramp 2 Ramp down
Time
0.05–3600 s *3.00s (10.00s)
(1)
3-8* Other Ramps
3-80 Jog Ramp Time
0.05–3600 s *3.00s (10.00s)
(1)
3-81 Quick Stop Ramp Time
0.05–3600 s *3.00 s (10.00s)
(1)
4-** Limits/Warnings
4-1* Motor Limits
4-10 Motor Speed Direction
*[0] Clockwise If Par. 1-00 is
set to close loop control
[1] CounterClockwise
*[2] Both if Par. 1-00 is set to
open loop control
4-12 Motor Speed Low Limit
[Hz]
0.0–400.0 Hz *0.0 Hz
4-14 Motor Speed High Limit
[Hz]
0.1–400.0 Hz *65.0 Hz
4-16 Torque Limit Motor
Mode
0–400% *150%
4-17 Torque Limit Generator
Mode
0–400% *100%
4-4* Adj. Warnings 2
4-40 Warning Frequency Low
0.00–Value of 4-41 Hz *0.0 Hz
4-41 Warning Frequency High
Value
Value of 4-40–400.0 Hz
*400.00 Hz
4-5* Adj. Warnings
4-50 Warning Current Low
0.00–100.00 A *0.00 A
4-51 Warning Current High
0.0–100.00 A *100.00 A
4-54 Warning Reference Low
-4999.000–Value of 4-55 *
-4999.000
4-55 Warning Reference High
Value of 4-54–4999.000
*4999.000
4-56 Warning Feedback Low
-4999.000–Value of 4-57 *
-4999.000
4-57 Warning Feedback High
Value of 4-56–4999.000
*4999.000
4-58 Missing Motor Phase
Function
[0] O
*[1] On
4-6* Speed Bypass
4-61 Bypass Speed From [Hz]
0.0–400.0 Hz *0.0 Hz
4-63 Bypass Speed To [Hz]
0.0–400.0 Hz *0.0 Hz
5-1* Digital Inputs
5-10 Terminal 18 Digital Input
[0] No function
[1] Reset
[2] Coast inverse
[3] Coast and reset inv.
[4] Quick stop inverse
[5] DC-brake inv.
[6] Stop inv
*[8] Start
[9] Latched start
[10] Reversing
[11] Start reversing
[12] Enable start forward
[13] Enable start reverse
[14] Jog
[16-18] Preset ref bit 0-2
[19] Freeze reference
[20] Freeze output
[21] Speed up
[22] Speed down
[23] Set-up select bit 0
[28] Catch up
[29] Slow down
[34] Ramp bit 0
[60] Counter A (up)
[61] Counter A (down)
[62] Reset counter A
[63] Counter B (up)
[64] Counter B (down)
[65] Reset counter B
5-11 Terminal 19 Digital Input
See par. 5-10. * [10] Reversing
5-12 Terminal 27 Digital Input
See par. 5-10. * [1] Reset
5-13 Terminal 29 Digital Input
See par. 5-10. * [14] Jog
5-15 Terminal 33 Digital Input
See par. 5-10. * [16] Preset ref
bit 0
[26] Precise Stop Inverse
[27] Start, Precise Stop
[32] Pulse Input
5-3* Digital Outputs
5-34 On Delay, Terminal 42
Digital Output
0.00–600.00 s * 0.01 s
5-35 O Delay, Terminal 42
Digital Output
0.00–600.00 s * 0.01 s
5-4* Relays
5-40 Function Relay
*[0] No operation
[1] Control ready
[2] Drive ready
1
M4 and M5 only.
AQ348848915086en-000101 / 130R094320 | Danfoss A/S © 2020.09
Parameter Overview
VLT® Micro Drive FC 51
Operating Guide
