Table 10: Parameter List
*[1] On
14-1* Mains monitoring
14-12 Function at mains im-
balance
*[0] Trip
[1] Warning
[2] Disabled
14-2* Trip Reset
14-20 Reset Mode
*[0] Manual reset
[1-9] AutoReset 1-9
[10] AutoReset 10
[11] AutoReset 15
[12] AutoReset 20
[13] Innite auto reset
[14] Reset at power up
14-21 Automatic Restart Time
0–600s * 10s
14-22 Operation Mode
*[0] Normal Operation
[2] Initialisation
14-26 Action At Inverter Fault
*[0] Trip
[1] Warning
14-4* Energy Optimising
14-41 AEO Minimum Magnet-
isation
40–75 %*66 %
14-9* Fault Settings
14-90 Fault level
[3] Trip Lock
[4] Trip with delayed reset
15-** Drive Information
15-0* Operating Data
15-00 Operating Days
15-01 Running Hours
15-02 kWh Counter
15-03 Power Ups
15-04 Over Temps
15-05 Over Volts
15-06 Reset kWh Counter
*[0] Do not reset
[1] Reset counter
15-07 Reset Running Hours
Counter
*[0] Do not reset
[1] Reset counter
15-3* Fault Log
15-30 Fault Log: Error Code
15-4* Drive Identication
15-40 FC Type
15-41 Power Section
15-42 Voltage
15-43 Software Version
15-46 Frequency Converter
Order. No
15-48 LCP Id No
15-51 Frequency Converter
Serial No
16-** Data Readouts
16-0* General Status
16-00 Control Word
0-0XFFFF
16-01 Reference [Unit]
-4999–4999 *0.000
16-02 Reference %
-200.0–200.0% *0.0%
16-03 Status Word
0–0XFFFF
16-05 Main Actual Value [%]
-200.0–200.0% *0.0%
16-09 Custom Readout
Dep. on par. 0-31, 0-32
16-1* Motor Status
16-10 Power [kW]
16-11 Power [hp]
16-12 Motor Voltage [V]
16-13 Frequency [Hz]
16-14 Motor Current [A]
16-15 Frequency [%]
16-18 Motor Thermal [%]
16-3* Drive Status
16-30 DC Link Voltage
16-34 Heat sink Temp.
16-35 Inverter Thermal
16-36 Inv.Nom. Current
16-37 Inv. Max. Current
16-38 SL Controller State
16-5* Ref./Feedb.
16-50 External Reference
16-51 Pulse Reference
16-52 Feedback [Unit]
16-6* Inputs/Outputs
16-60 Digital Input
18,19,27,33
0-1111
16-61 Digital Input 29
0-1
16-62 Analog Input 53 (volt)
16-63 Analog Input 53 (cur-
rent)
16-64 Analog Input 60
16-65 Analog Output 42 [mA]
16-68 Pulse Input [Hz]
16-71 Relay Output [bin]
16-72 Counter A
16-73 Counter B
16-8* Fieldbus/FC Port
16-86 FC Port REF 1
0x8000-0x7FFFF
16-9* Diagnosis Readouts
16-90 Alarm Word
0-0XFFFFFFFF
16-92 Warning Word
0-0XFFFFFFFF 16-94 Ext. Sta-
tus Word
0-0XFFFFFFFF
18-** Extended Motor Data
18-8* Motor Resistors
18-80 Stator Resistance (High
resolution)
0.000–99.990 ohm *0.000
ohm
18-81 Stator Leakage Reac-
tance(High resolution)
0.000–99.990 ohm *0.000
ohm
AQ348848915086en-000101 / 130R0943 | 23Danfoss A/S © 2020.09
Parameter Overview
VLT® Micro Drive FC 51
Operating Guide
