Type Description Comments
Options for Slot A Ordering no.
Coated
Options for Slot B
MCB 101 General purpose Input Output option
MCB 105 Relay option
MCB 109 Analog I/O option and battery back-up for real-time clock 130B1243
MCB 112 ATEX PTC 130B1137
MCB 114
Sensor input - unocated 130B1172
Sensor input - coated 130B1272
Option for Slot D
MCB 107 24 V DC back-up 130B1208
External Options
Table 4.4
For information on fieldbus and application option compatibility with
older software versions, please contact your Danfoss supplier.
Type Description
Spare Parts Ordering no. Comments
Control board FC With Safe Stop Function 130B1150
Control board FC Without Safe Stop Function 130B1151
Fan A2 Fan, frame size A2 130B1009
Fan A3 Fan, frame size A3 130B1010
Fan A5 Fan, frame size A5 130B1017
Fan B1 Fan external, frame size B1 130B3407
Fan B2 Fan external, frame size B2 130B3406
Fan B3 Fan external, frame size B3 130B3563
Fan B4 Fan external, 18.5/22 kW 130B3699
Fan B4 Fan external 22/30 kW 130B3701
Fan C1 Fan external, frame size C1 130B3865
Fan C2 Fan external, frame size C2 130B3867
Fan C3 Fan external, frame size C3 130B4292
Fan C4 Fan external, frame size C4 130B4294
Miscellaneous hardware II
Accessory bag A2 Accessory bag, frame size A2 130B1022
Accessory bag A3 Accessory bag, frame size A3 130B1022
Accessory bag A5 Accessory bag, frame size A5 130B1023
Accessory bag B1 Accessory bag, frame size B1 130B2060
Accessory bag B2 Accessory bag, frame size B2 130B2061
Accessory bag B3 Accessory bag, frame size B3 130B0980
Accessory bag B4 Accessory bag, frame size B4 130B1300 Small
Accessory bag B4 Accessory bag, frame size B4 130B1301 Big
Accessory bag C1 Accessory bag, frame size C1 130B0046
Accessory bag C2 Accessory bag, frame size C2 130B0047
Accessory bag C3 Accessory bag, frame size C3 130B0981
Accessory bag C4 Accessory bag, frame size C4 130B0982 Small
Accessory bag C4 Accessory bag, frame size C4 130B0983 Big
Table 4.5
How to Order
VLT
®
Refrigeration Drive Design Guide
54 MG16G102 - VLT
®
is a registered Danfoss trademark
4
4
